DC Brushless Fans (BLDC)
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Voltage - Rated | Size / Dimension | Width | Air Flow | Static Pressure | Bearing Type | Fan Type | Features | Noise | Power (Watts) | RPM | Termination | Ingress Protection | Operating Temperature | Approval Agency | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
DC0922548V2B-3T1FAN 92X25MM 48VDC TACH COMPUTER |
1,294 | 0.00 |
|
Datasheet |
- | Bulk | Active | 48VDC | Square - 92mm L x 92mm H | 25.00mm | 81.0 CFM (2.27m³/min) | 0.400 in H2O (99.6 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 49.0dB(A) | 19.68 W | 4500 RPM | 3 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
|
DC0402824L2B-3T0FAN 40X28MM 24VDC TACH |
3,970 | 0.00 |
|
Datasheet |
- | Bulk | Active | 24VDC | Square - 40mm L x 40mm H | 28.00mm | 13.8 CFM (0.386m³/min) | 0.460 in H2O (114.6 Pa) | Ball | Tubeaxial | Locked Rotor Protection, Speed Sensor (Tach) | 38.0dB(A) | 3.36 W | 8000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus | - |
|
|
PF92252B1-1000U-F9924VDC FAN 92X25MM TACH |
2,971 | 0.00 |
|
Datasheet |
PF | Box | Active | 24VDC | Square - 92mm L x 92mm H | 25.00mm | 75.0 CFM (2.10m³/min) | 0.350 in H2O (87.2 Pa) | Ball | Tubeaxial | Auto Restart, Locked Rotor Sensor | 46.1dB(A) | 4.92 W | 4500 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
CFM-6025BG68-1120-587-22DC AXIAL FAN, 60 MM SQUARE, 25 M |
1,946 | 0.00 |
|
Datasheet |
CFM-60BG68 | Box | Active | 12VDC | Square - 60mm L x 60mm H | 25.00mm | 52.4 CFM (1.47m³/min) | 1.700 in H2O (423.5 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 58.7dB(A) | 17.76 W | 12000 RPM | 4 Wire Leads | IP68 - Dust Tight, Waterproof | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
AFB0912SHFAN 12VDC 102.59CFM 92MM X 4MM |
3,815 | 0.00 |
|
- |
- | - | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
EEC0381B2-000U-G9912VDC FAN 120X38MM ALARM |
4,240 | 0.00 |
|
Datasheet |
EE | Box | Active | 12VDC | Square - 120mm L x 120mm H | 38.00mm | 116.0 CFM (3.25m³/min) | 0.260 in H2O (64.8 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 44.0dB(A) | 5.1 W | 2600 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
EEC0381B3-000U-G9912VDC FAN 120X38MM ALARM |
4,754 | 0.00 |
|
Datasheet |
EE | Box | Active | 12VDC | Square - 120mm L x 120mm H | 38.00mm | 93.0 CFM (2.60m³/min) | 0.180 in H2O (44.8 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 37.0dB(A) | 2.9 W | 2100 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
EEC0381B1-000U-G9912VDC FAN 120X38MM ALARM |
2,051 | 0.00 |
|
Datasheet |
EE | Box | Active | 12VDC | Square - 120mm L x 120mm H | 38.00mm | 137.7 CFM (3.86m³/min) | 0.360 in H2O (89.6 Pa) | Ball | Tubeaxial | Auto Restart, Speed Sensor (Tach) | 48.0dB(A) | 10 W | 3100 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
PF40281B1-1000U-S9HFAN AXIAL 40X28MM 12VDC WIRE |
2,995 | 0.00 |
|
Datasheet |
PF | Bulk | Active | 12VDC | Square - 40mm L x 40mm H | 28.00mm | 24.9 CFM (0.697m³/min) | 2.050 in H2O (510.6 Pa) | Ball | Tubeaxial | Auto Restart, PWM Control, Speed Sensor (Tach) | 56.0dB(A) | 6.12 W | 17600 RPM | 4 Wire Leads | - | - | CCC, CE, cURus, TUV | - |
|
|
PF75301B2-1B00U-F9912VDC FAN 75X30MM TACH |
3,821 | 0.00 |
|
Datasheet |
PF | Box | Active | 12VDC | Square/Rounded - 75mm L x 75mm H | 30.00mm | 13.8 CFM (0.386m³/min) | 0.430 in H2O (107.1 Pa) | Ball | Blower | Auto Restart, Locked Rotor Sensor | 38.6dB(A) | 1.71 W | 3000 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
PF75301B3-1B00U-F9912VDC FAN 75X30MM TACH |
1,119 | 0.00 |
|
Datasheet |
PF | Box | Active | 12VDC | Square/Rounded - 75mm L x 75mm H | 30.00mm | 10.8 CFM (0.302m³/min) | 0.240 in H2O (59.8 Pa) | Ball | Blower | Auto Restart, Locked Rotor Sensor | 32.9dB(A) | 0.99 W | 2400 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
PF75301B1-1B00U-F9912VDC FAN 75X30MM TACH |
1,132 | 0.00 |
|
Datasheet |
PF | Box | Active | 12VDC | Square/Rounded - 75mm L x 75mm H | 30.00mm | 15.5 CFM (0.434m³/min) | 0.570 in H2O (142.0 Pa) | Ball | Blower | Auto Restart, Locked Rotor Sensor | 42.0dB(A) | 2.4 W | 3400 RPM | 3 Wire Leads | - | - | CCC, CE, cURus, TUV, UKCA | - |
|
|
DC0402812L2B-2T2FAN 40X28MM 12VDC MOLEX 22-01-10 |
1,306 | 0.00 |
|
Datasheet |
- | Bulk | Active | 12VDC | Square - 40mm L x 40mm H | 28.00mm | 15.9 CFM (0.445m³/min) | 0.690 in H2O (171.8 Pa) | Ball | Tubeaxial | Locked Rotor Protection | 44.0dB(A) | 3.12 W | 9500 RPM | 2 Position Rectangular Connector | - | 14 ~ 158°F (-10 ~ 70°C) | CE, cURus, TUV | - |
|
|
MS9238L24B-FHRFAN AXIAL 92X38MM 24VDC WIRE |
2,134 | 13.56 |
|
Datasheet |
MS9238-H | Bulk | Active | 24VDC | Square - 92mm L x 92mm H | 38.00mm | 80.7 CFM (2.26m³/min) | 0.400 in H2O (99.6 Pa) | Ball | Tubeaxial | Auto Restart | 37.0dB(A) | - | 4000 RPM | 2 Wire Leads | - | - | - | 0.446 lb (202.3 g) |
|
|
MS9238M24B-FHRFAN AXIAL 92X38MM 24VDC WIRE |
1,752 | 13.56 |
|
Datasheet |
MS9238-H | Bulk | Active | 24VDC | Square - 92mm L x 92mm H | 38.00mm | 125.3 CFM (3.51m³/min) | 0.870 in H2O (216.7 Pa) | Ball | Tubeaxial | Auto Restart | 56.0dB(A) | - | 6000 RPM | 2 Wire Leads | - | - | - | 0.446 lb (202.3 g) |
|
|
MS9238H48B-FHRFAN AXIAL 92X38MM 48VDC WIRE |
1,360 | 13.56 |
|
Datasheet |
MS9238-H | Bulk | Active | 48VDC | Square - 92mm L x 92mm H | 38.00mm | 166.7 CFM (4.67m³/min) | 1.450 in H2O (361.2 Pa) | Ball | Tubeaxial | Auto Restart | 65.0dB(A) | - | 8000 RPM | 2 Wire Leads | - | - | - | 0.446 lb (202.3 g) |
|
|
MS9238H24B-FHRFAN AXIAL 92X38MM 24VDC WIRE |
4,544 | 13.56 |
|
Datasheet |
MS9238-H | Bulk | Active | 24VDC | Square - 92mm L x 92mm H | 38.00mm | 166.7 CFM (4.67m³/min) | 1.450 in H2O (361.2 Pa) | Ball | Tubeaxial | Auto Restart | 65.0dB(A) | - | 8000 RPM | 2 Wire Leads | - | - | - | 0.446 lb (202.3 g) |
|
G8032H12B1-RSR-WS-EMFAN AXIAL 80X32MM 12VDC WIRE |
1,640 | 15.88 |
|
Datasheet |
G8032 | Bulk | Active | 12VDC | Square - 80mm L x 80mm H | 32.00mm | 48.0 CFM (1.34m³/min) | 0.370 in H2O (92.2 Pa) | Ball | Tubeaxial | Alarm Sensor, Speed Sensor (Tach), Thermal Overload Protector (TOP) | 42.0dB(A) | - | 4000 RPM | 4 Wire Leads | IP57 - Dust Protected, Waterproof | - | CE, cUL, TUV, UL | 0.286 lb (129.73 g) |
|
G1238E12B1-FSR-WSFAN AXIAL 119X38MM 12VDC WIRE |
1,568 | 15.88 |
|
Datasheet |
G1238 | Bulk | Active | 12VDC | Square - 119mm L x 119mm H | 38.00mm | 158.0 CFM (4.42m³/min) | 0.490 in H2O (122.1 Pa) | Ball | Tubeaxial | Alarm Sensor, Speed Sensor (Tach), Thermal Overload Protector (TOP) | 49.0dB(A) | - | 3600 RPM | 4 Wire Leads | - | - | CE, cUL, TUV, UL | 0.74 lb (335.66 g) |
|
G1238E24B1-FSRFAN AXIAL 119X38MM 24VDC WIRE |
1,923 | 15.88 |
|
Datasheet |
G1238 | Bulk | Active | 24VDC | Square - 119mm L x 119mm H | 38.00mm | 158.0 CFM (4.42m³/min) | 0.490 in H2O (122.1 Pa) | Ball | Tubeaxial | Speed Sensor (Tach), Thermal Overload Protector (TOP) | 49.0dB(A) | - | 3600 RPM | 3 Wire Leads | - | - | CE, cUL, TUV, UL | 0.74 lb (335.66 g) |
