Fixed Inductors
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PM42S-390FIXED IND 39UH 300MA 709MOHM SMD |
3,975 | 0.00 |
|
Datasheet |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 39 µH | ±30% | 300 mA | - | Shielded | 709mOhm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-3R3FIXED IND 3.3UH 1.04A 110MOHM SM |
1,954 | 0.00 |
|
Datasheet |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 3.3 µH | ±30% | 1.04 A | - | Shielded | 110mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-560FIXED IND 56UH 260MA 1.08OHM SMD |
4,844 | 0.00 |
|
Datasheet |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 56 µH | ±30% | 260 mA | - | Shielded | 1.08Ohm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-5R6FIXED IND 5.6UH 800MA 170MOHM SM |
1,359 | 0.00 |
|
Datasheet |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 5.6 µH | ±30% | 800 mA | - | Shielded | 170mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-820FIXED IND 82UH 220MA 1.56OHM SMD |
3,266 | 0.00 |
|
Datasheet |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 82 µH | ±30% | 220 mA | - | Shielded | 1.56Ohm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-8R2FIXED IND 8.2UH 680MA 245MOHM SM |
3,252 | 0.00 |
|
Datasheet |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 8.2 µH | ±30% | 680 mA | - | Shielded | 245mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
PM43-1R0MFIXED IND 1UH 2.56A 49 MOHM SMD |
1,462 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1 µH | ±20% | 2.56 A | - | Unshielded | 49mOhm | - | 113MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-1R4MFIXED IND 1.4UH 2.52A 57MOHM SMD |
4,554 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1.4 µH | ±20% | 2.52 A | - | Unshielded | 57mOhm | - | 101MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-1R8MFIXED IND 1.8UH 1.95A 64MOHM SMD |
1,385 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1.8 µH | ±20% | 1.95 A | - | Unshielded | 64mOhm | - | 92MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-2R2MFIXED IND 2.2UH 1.75A 72MOHM SMD |
4,263 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 2.2 µH | ±20% | 1.75 A | - | Unshielded | 72mOhm | - | 76MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-2R7MFIXED IND 2.7UH 1.58A 79MOHM SMD |
4,162 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 2.7 µH | ±20% | 1.58 A | - | Unshielded | 79mOhm | - | 66MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-3R3MFIXED IND 3.3UH 1.44A 87MOHM SMD |
3,019 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 3.3 µH | ±20% | 1.44 A | - | Unshielded | 87mOhm | - | 63MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-4R7MFIXED IND 4.7UH 1.15A 109MOHM SM |
1,609 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 4.7 µH | ±20% | 1.15 A | - | Unshielded | 109mOhm | - | 49MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-5R6MFIXED IND 5.6UH 990MA 126MOHM SM |
1,992 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 5.6 µH | ±20% | 990 mA | - | Unshielded | 126mOhm | - | 43MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-6R8MFIXED IND 6.8UH 950MA 132MOHM SM |
4,131 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 6.8 µH | ±20% | 950 mA | - | Unshielded | 132mOhm | - | 41MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-8R2MFIXED IND 8.2UH 840MA 147MOHM SM |
1,680 | 0.00 |
|
Datasheet |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 8.2 µH | ±20% | 840 mA | - | Unshielded | 147mOhm | - | 35MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
PM5022S-100MFIXED IND 10UH 3.9A 40 MOHM SMD |
3,009 | 0.00 |
|
Datasheet |
PM5022S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 10 µH | ±20% | 3.9 A | 8A | Shielded | 40mOhm Max | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.732" L x 0.602" W (18.60mm x 15.30mm) | 0.299" (7.60mm) |
|
|
PM5022S-102MFIXED IND 1MH 530MA 2.01 OHM SMD |
1,006 | 0.00 |
|
Datasheet |
PM5022S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1 mH | ±20% | 530 mA | 800mA | Shielded | 2.01Ohm Max | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.732" L x 0.602" W (18.60mm x 15.30mm) | 0.299" (7.60mm) |
|
|
PM5022S-150MFIXED IND 15UH 3.4A 48 MOHM SMD |
3,004 | 0.00 |
|
Datasheet |
PM5022S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 15 µH | ±20% | 3.4 A | 7A | Shielded | 48mOhm Max | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.732" L x 0.602" W (18.60mm x 15.30mm) | 0.299" (7.60mm) |
|
|
PM5022S-151MFIXED IND 150UH 1.3A 293MOHM SMD |
3,000 | 0.00 |
|
Datasheet |
PM5022S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 150 µH | ±20% | 1.3 A | 2.1A | Shielded | 293mOhm Max | - | - | - | -40°C ~ 85°C | 100 kHz | - | Surface Mount | - | 0.732" L x 0.602" W (18.60mm x 15.30mm) | 0.299" (7.60mm) |
