Pulse Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TG10G-RP02NJLFTRISO MOD 10G POE 0.45A 24P SMD T/ |
1,001 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10G Base-T | - | - | - | Surface Mount | 0.545" L x 0.480" W (13.84mm x 12.19mm) | 0.250" (6.35mm) | 0°C ~ 70°C | - | - |
|
|
TG1G-S041NURLTRISO MOD 1G 32P SMD T/R |
3,437 | 0.00 |
|
- |
- | Tape & Reel (TR) | Not For New Designs | Isolation and Data Interface (Encapsulated) | 350µH | - | 1CT:1CT | Surface Mount | 1.000" L x 0.300" W (25.40mm x 7.62mm) | 0.290" (7.37mm) | 0°C ~ 70°C | - | - |
|
|
TG111-S001J24RLTRISO MID 1G LOWPRFL 24P SMD T/R |
1,180 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10/100 Base-TX | 350µH | - | 1CT:1CT | Surface Mount | 0.520" L x 0.480" W (13.21mm x 12.19mm) | 0.148" (3.75mm) | 0°C ~ 70°C | - | - |
|
|
TG110-BCM2NXRLTRISO MOD 10/100 QUAD 40P SMD T/R |
2,589 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10/100 Base-TX | - | - | 1CT:1CT | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
|
TG10G-S102NJLFISO MOD 10G 24P SMD |
4,408 | 0.00 |
|
Datasheet |
- | Tube | Active | LAN 10G Base-T | - | - | - | Surface Mount | 0.545" L x 0.480" W (13.84mm x 12.19mm) | 0.250" (6.35mm) | 0°C ~ 70°C | - | - |
|
749010110TRANSFORMER LAN 10/100 SMD |
1,275 | 6.56 |
|
Datasheet |
WE-LAN | Tape & Reel (TR) | Obsolete | LAN 10/100 Base-T | 350µH | - | 1:1 | Surface Mount | 0.505" L x 0.280" W (12.83mm x 7.11mm) | 0.085" (2.16mm) | - | - | - |
|
|
TG1G-E001NYRLTRISO MOD 1G X-TEMP 24P SMD T/R |
4,148 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10/100 Base-TX | 350µH | - | 1CT:1CT | Surface Mount | 0.600" L x 0.540" W (15.24mm x 13.72mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
TG23-1505NXLFISO MOD T1 4P 1:2.42 X-TEMP 40P |
3,915 | 0.00 |
|
Datasheet |
- | Tube | Active | T1/E1 (Quad) | 1.5mH | - | 1:2.42 Transmitter, 1:2.42 Receiver | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.230" (5.84mm) | -40°C ~ 85°C | - | - |
|
|
TG110-6506NXRLTRISO MOD 10/100 QUAD 40P SMD T/R |
2,134 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10/100 Base-TX | - | - | 1CT:1CT, 1:1 | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
|
TG110-S453NXLFTRISO MOD 10/100 QUAD 40P SMD T/R |
1,926 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10/100 Base-TX | - | - | - | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
|
TG110-S452NXLFTRISO MOD 10/100 QUAD 40P SMD T/R |
2,229 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10/100 Base-TX | - | - | - | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
|
TG110-S450NXLFTRISO MOD 10/100 QUAD 40P SMD T/R |
4,366 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10/100 Base-TX | - | - | - | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
750051967TRANSFORMER DSL EP13 SMD |
2,143 | 5.07 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | - | - | - | Surface Mount | - | - | - | - | - |
|
|
TG49-LVL1NXLFTRISO MOD T1 QUAD 1C:2 1:2C X-TEMP |
4,616 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | T1/E1 (Quad) | 1.5mH | - | 1:2CT Transmitter, 1CT:2 Receiver | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.230" (5.84mm) | -40°C ~ 85°C | - | - |
|
|
TG111-E112NYLFTRISO MOD 1G POE 0.35A X-TEMP 24P |
3,653 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10/100 Base-TX | 350µH | - | 1CT:1CT | Surface Mount | 0.600" L x 0.540" W (15.24mm x 13.72mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
TG2G-HPE6NZLFISO MOD 2.5G POE 0.6A X-TEMP 24 |
3,419 | 0.00 |
|
Datasheet |
- | Tube | Active | LAN 2.5G Base-T, Power over Ethernet (PoE) | - | - | 1:1 | Surface Mount | 0.722" L x 0.485" W (18.33mm x 12.32mm) | 0.230" (5.84mm) | -40°C ~ 85°C | - | - |
|
|
T1145NLTXFRM T1/E1/CEPT/ISDN-PRI 1:2/2.4 |
1,134 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Obsolete | T1/E1 (Quad) | 1mH, 1mH | - | 1:2/2.4 Transmitter, 1:0.79/1 Receiver | Surface Mount | 1.125" L x 0.485" W (28.58mm x 12.32mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
|
TG10G-S100NJRLTRISO MOD 10G 24P SMD T/R |
2,413 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10G Base-T | - | - | - | Surface Mount | 0.545" L x 0.480" W (13.84mm x 12.19mm) | 0.250" (6.35mm) | 0°C ~ 70°C | - | - |
|
|
TG10G-S101NJLFISO MOD 10G 24P SMD |
3,666 | 0.00 |
|
Datasheet |
- | Tube | Active | LAN 10G Base-T | - | - | - | Surface Mount | 0.545" L x 0.480" W (13.84mm x 12.19mm) | 0.250" (6.35mm) | 0°C ~ 70°C | - | - |
|
|
TG05-2004NCRLISO MOD 64KB 2CH 1:2C 12P SMD |
2,088 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | Isolation and Data Interface (Encapsulated) | 20mH | - | 1:2CT | Surface Mount | 0.675" L x 0.455" W (17.15mm x 11.56mm) | 0.340" (8.64mm) | 0°C ~ 70°C | - | - |
