TVS Diodes
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Unidirectional Channels | Bidirectional Channels | Voltage - Reverse Standoff (Typ) | Voltage - Breakdown (Min) | Voltage - Clamping (Max) @ Ipp | Current - Peak Pulse (10/1000µs) | Power - Peak Pulse | Power Line Protection | Applications | Capacitance @ Frequency | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ESD05B1ZTVS DIODE 5VWM 11VC 0201 |
3,201 | 0.18 |
|
Datasheet |
0201 (0603 Metric) | - | Bulk | Active | Zener | - | 1 | 5V (Max) | 5.8V | 11V | 17A (8/20µs) | 170W | No | General Purpose | 25pF @ 1MHz | -50°C ~ 125°C (TJ) | - | - | Surface Mount | 0201 |
|
DF2S30ASL,L3FSOD-962 VRMW 23V 1UA TVS DIODES |
3,562 | 0.00 |
|
- |
2-SMD, No Lead | - | Tape & Reel (TR) | Active | Zener | 1 | - | 23V (Max) | 28V | 58V | 2.5A (8/20µs) | 145W | No | General Purpose | 7.5pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S16ASL,L3FSOD-962 VRMW 12V 1UA TVS DIODES |
6,208 | 0.00 |
|
- |
2-SMD, No Lead | - | Tape & Reel (TR) | Active | Zener | 1 | - | 12V (Max) | 15.3V | 35V | 2.5A (8/20µs) | 87W | No | General Purpose | 10pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S20ASL,L3FSOD-962 VRMW 15V 1UA TVS DIODES |
2,354 | 0.00 |
|
- |
2-SMD, No Lead | - | Tape & Reel (TR) | Active | Zener | 1 | - | 15V (Max) | 18.8V | 42V | 2.5A (8/20µs) | 105W | No | General Purpose | 9.5pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S12ASL,L3FSOD-962 VRMW 9V 1UA TVS DIODES |
7,147 | 0.00 |
|
- |
2-SMD, No Lead | - | Tape & Reel (TR) | Active | Zener | 1 | - | 9V (Max) | 11.4V | 29V | 2.5A (8/20µs) | 72W | No | General Purpose | 13pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S24ASL,L3FSOD-962 VRMW 19V 1UA TVS DIODES |
2,674 | 0.00 |
|
- |
0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | 1 | - | 19V (Max) | 22.8V | 47V | 2.5A (8/20µs) | 117W | No | General Purpose | 8.5pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
|
DF2S10ASL,L3FSOD-962 VRMW 8V AT 1UA TVS DIODE |
5,929 | 0.00 |
|
- |
0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | 1 | - | 8V (Max) | 9.4V | 24V | 2.5A (8/20µs) | 60W | No | General Purpose | 16pF @ 1MHz | 150°C (TJ) | - | - | Surface Mount | SL2 |
|
ESDBK3V3TVS DIODE 3.3VWM 9VC SOD-882 |
3,625 | 0.04 |
|
Datasheet |
SOD-882 | - | Bulk | Active | Zener | - | 1 | 3.3V | 4V | 9V | 7A (8/20µs) | 60W | No | General Purpose | 15pF @ 1MHz | -50°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-882 (DFN1006-2) |
|
|
PESD6V3S1ULYLPESD6V3S1UL/SOD882/DFN1006-2 |
6,336 | 0.00 |
|
Datasheet |
SOD-882 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 6.3V (Max) | 7.1V | 13.4V (Typ) | 10.4A (8/20µs) | - | No | General Purpose | 82pF @ 1MHz | -55°C ~ 150°C (TA) | - | - | Surface Mount | DFN1006-2 |
|
|
PESD8V0S1ULYLPESD8V0S1UL/SOD882/DFN1006-2 |
2,806 | 0.00 |
|
Datasheet |
SOD-882 | - | Tape & Reel (TR) | Active | Zener | 1 | - | 8V (Max) | 8.65V | 15.5V (Typ) | 8.5A (8/20µs) | - | No | - | 70pF @ 1MHz | -55°C ~ 150°C (TA) | Automotive | AEC-Q101 | Surface Mount | DFN1006-2 |
|
|
PESD3V3L1BSFYLPESD3V3L1BSF/SOD962-2/SOD962-2 |
9,024 | 0.00 |
|
Datasheet |
0201 (0603 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 3.3V (Max) | 7.3V (Typ) | 5.6V (Typ) | 20A (8/20µs) | - | No | Telecom | 32.5pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | DSN0603-2 |
|
|
D12V0HE1U2LP-7BGENERAL PROTECTION PP X1-DFN1006 |
2,701 | 0.00 |
|
- |
0402 (1006 Metric) | - | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | X1-DFN1006-2 |
|
|
PTVS6V3Z1UCLZPTVS6V3Z1UCL/SOD882/DFN1006-2 |
8,434 | 0.00 |
|
Datasheet |
2-XDFN | - | Tape & Reel (TR) | Active | Zener | 1 | - | 6.3V (Max) | 6.4V | 12V | 40A (8/20µs) | - | No | General Purpose | 100pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | DFN1006-2 |
|
|
PTVS5V0Z1UCLZPTVS5V0Z1UCL/SOD882/DFN1006-2 |
8,066 | 0.00 |
|
Datasheet |
2-XDFN | - | Tape & Reel (TR) | Active | Zener | 1 | - | 5V (Max) | 5.1V | 10V | 44A (8/20µs) | - | No | General Purpose | 160pF @ 1MHz | -40°C ~ 125°C (TA) | - | - | Surface Mount | DFN1006-2 |
|
|
CPDQT5V0ESPC-HFDIODE ESD 5VWM 85W 0402/DFN1006- |
5,029 | 0.00 |
|
Datasheet |
0402 (1006 Metric) | - | Tape & Reel (TR) | Active | Zener | - | 1 | 5V (Max) | 6.8V | 20V (Typ) | 4A (8/20µs) | 85W | No | General Purpose | 0.2pF @ 1MHz | -40°C ~ 125°C (TJ) | - | - | Surface Mount | DFN1006-2L |
|
|
ESDHD12UCXESDHD12UC/SOD323/REEL 7" Q1/T1 * |
6,949 | 0.00 |
|
Datasheet |
SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 12V (Max) | 13.3V | 35V | 15A (8/20µs) | 300W | No | General Purpose | 150pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
|
|
ESDHD03UCXESDHD03UC/SOD323/REEL 7" Q1/T1 * |
9,660 | 0.00 |
|
Datasheet |
SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 3.3V (Max) | 4V | 18V | 30A (8/20µs) | 300W | No | General Purpose | 300pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
|
|
ESDHD15UCXESDHD15UC/SOD323/REEL 7" Q1/T1 * |
9,450 | 0.00 |
|
Datasheet |
SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 15V (Max) | 16.3V | 45V | 10A (8/20µs) | 300W | No | General Purpose | 120pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
|
|
ESDHD24UCXESDHD24UC/SOD323/REEL 7" Q1/T1 * |
8,274 | 0.00 |
|
Datasheet |
SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 24V (Max) | 26V | 55V | 6A (8/20µs) | 300W | No | General Purpose | 80pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
|
|
ESDHD05UCXESDHD05UC/SOD323/REEL 7" Q1/T1 * |
3,018 | 0.00 |
|
Datasheet |
SC-76, SOD-323 | ESDHDxxUC | Tape & Reel (TR) | Active | Zener | 1 | - | 5V (Max) | 6V | 20V | 30A (8/20µs) | 300W | No | General Purpose | 300pF @ 1MHz | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOD-323 |
