Arrays, Signal Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Number of Coils | Inductance - Connected In Parallel | Inductance - Connected In Series | Tolerance | Current Rating - Parallel | Current Rating - Series | Current Saturation - Parallel | Current Saturation - Series | DC Resistance (DCR) - Parallel | DC Resistance (DCR) - Series | Shielding | Ratings | Operating Temperature | Mounting Type | Size / Dimension | Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PF0553.334NLTINDUCT ARRAY 2 COIL 330UH SMD |
2,307 | 0.00 |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 330 µH | 1.3 mH | ±20% | 1 A | 510 mA | 2 A | 1 A | 570mOhm Max | 2.3mOhm Max | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
|
PF0553.105NLTINDUCT ARRAY 2 COIL 1MH SMD |
1,354 | 0.00 |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 1 mH | 4 mH | ±20% | 610 mA | 310 mA | 1.1 A | 570 mA | 1.6Ohm Max | 6.5Ohm Max | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
|
PF0553.332NLTINDUCT ARRAY 2 COIL 2.8UH SMD |
2,849 | 0.00 |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 2.8 µH | 11.3 µH | ±20% | 10 A | 5.2 A | 21 A | 11 A | 5.4mOhm Max | 22mOhm Max | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
|
PF0553.104NLTINDUCT ARRAY 2 COIL 100UH SMD |
1,183 | 0.00 |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 100 µH | 400 µH | ±20% | 1.9 A | 970 mA | 3.6 A | 1.8 A | 160mOhm Max | 650mOhm Max | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
|
PF0553.474NLTINDUCT ARRAY 2 COIL 470UH SMD |
4,367 | 0.00 |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 470 µH | 1.9 mH | ±20% | 830 mA | 420 mA | 1.7 A | 840 mA | 860mOhm Max | 3.4Ohm Max | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
|
PF0553.154NLTINDUCT ARRAY 2 COIL 150UH SMD |
1,287 | 0.00 |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 150 µH | 600 µH | ±20% | 1.6 A | 780 mA | 3 A | 1.5 A | 250mOhm Max | 990mOhm Max | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
P0398NLTINDUCT ARRAY 2 COIL 7.9UH SMD |
4,336 | 0.00 |
|
Datasheet |
Tomcat | Nonstandard | Tape & Reel (TR) | Active | 2 | 7.9 µH | 31.5 µH | ±20% | 6.8 A | 3.4 A | - | - | 14.94mOhm | 59.7mOhm | Unshielded | - | -40°C ~ 130°C | Surface Mount | 0.715" L x 0.590" W (18.16mm x 14.99mm) | 0.310" (7.87mm) |
|
|
PF0553.822NLTINDUCT ARRAY 2 COIL 8.9UH SMD |
4,819 | 0.00 |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 8.9 µH | 35 µH | ±20% | 6.2 A | 3.1 A | 12 A | 6.1 A | 15mOhm Max | 62mOhm Max | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
|
PF0553.823NLTINDUCT ARRAY 2 COIL 80UH SMD |
2,089 | 0.00 |
|
Datasheet |
PF0553NL | Nonstandard | Tape & Reel (TR) | Active | 2 | 80 µH | 320 µH | ±20% | 2 A | 1 A | 4.1 A | 2 A | 140mOhm Max | 570mOhm Max | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.315" (8.00mm) |
|
P0402INDUCT ARRAY 2 COIL 40.5UH SMD |
2,986 | 0.00 |
|
Datasheet |
Tomcat | Nonstandard | Tube | Obsolete | 2 | 40.5 µH | 161.8 µH | ±20% | 3.54 A | 1.77 A | - | - | 53.21mOhm | 212.8mOhm | Unshielded | - | -40°C ~ 130°C | Surface Mount | 0.715" L x 0.590" W (18.16mm x 14.99mm) | 0.310" (7.87mm) |
|
PM600-01-RCINDUCT ARRAY 6 COIL 201.6UH SMD |
3,665 | 4.53 |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 201.6 µH | 7.25 mH | ±30% | 2.76 A | 460 mA | 120 mA | 20 mA | 54mOhm | 1.944Ohm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.500" L x 0.480" W (12.70mm x 12.20mm) | 0.244" (6.20mm) |
|
|
PM600-02-RCINDUCT ARRAY 6 COIL 89.6UH SMD |
4,369 | 4.53 |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 89.6 µH | 3.23 mH | ±30% | 4.26 A | 710 mA | 180 mA | 30 mA | 23mOhm | 822mOhm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.500" L x 0.480" W (12.70mm x 12.20mm) | 0.244" (6.20mm) |
|
|
PM600-03-RCINDUCT ARRAY 6 COIL 27.4UH SMD |
1,849 | 4.53 |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 27.4 µH | 986.4 µH | ±10% | 2.76 A | 460 mA | 1.86 A | 310 mA | 54mOhm | 1.944Ohm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.500" L x 0.480" W (12.70mm x 12.20mm) | 0.244" (6.20mm) |
|
|
PM600-04-RCINDUCT ARRAY 6 COIL 12.2UH SMD |
3,138 | 4.53 |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 12.2 µH | 439.2 µH | ±10% | 4.26 A | 710 mA | 2.82 A | 470 mA | 23mOhm | 822mOhm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.500" L x 0.480" W (12.70mm x 12.20mm) | 0.244" (6.20mm) |
|
|
PM600-10-RCINDUCT ARRAY 6 COIL 3.8UH SMD |
1,143 | 4.53 |
|
Datasheet |
PM600 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 3.8 µH | 136.8 µH | ±10% | 4.26 A | 710 mA | 11.1 A | 1.85 A | 23mOhm | 822mOhm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.500" L x 0.480" W (12.70mm x 12.20mm) | 0.244" (6.20mm) |
|
|
PM610-01-RCINDUCT ARRAY 6 COIL 160UH SMD |
3,300 | 4.84 |
|
Datasheet |
PM610 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 160 µH | 5.76 mH | ±30% | 4.08 A | 680 mA | 240 mA | 40 mA | 34mOhm | 1.212Ohm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.591" L x 0.630" W (15.00mm x 16.00mm) | 0.307" (7.80mm) |
|
PM610-05-RCINDUCT ARRAY 6 COIL 11.6UH SMD |
4,075 | 4.84 |
|
Datasheet |
PM610 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 11.6 µH | 417.6 µH | ±10% | 4.08 A | 680 mA | 7.8 A | 1.3 A | 34mOhm | 1.212Ohm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.591" L x 0.630" W (15.00mm x 16.00mm) | 0.307" (7.80mm) |
|
|
PM610-10-RCINDUCT ARRAY 6 COIL 3.2UH SMD |
1,472 | 4.84 |
|
Datasheet |
PM610 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 3.2 µH | 115.2 µH | ±10% | 6 A | 1 A | 19.74 A | 3.29 A | 16mOhm | 564mOhm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.591" L x 0.630" W (15.00mm x 16.00mm) | 0.307" (7.80mm) |
|
|
PM620-01-RCINDUCT ARRAY 6 COIL 160.6UH SMD |
2,139 | 4.99 |
|
Datasheet |
PM620 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 160.6 µH | 5.78 mH | ±30% | 7.68 A | 1.28 A | 180 mA | 30 mA | 16mOhm | 564mOhm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.669" L x 0.843" W (17.00mm x 21.40mm) | 0.331" (8.40mm) |
|
|
PM620-03-RCINDUCT ARRAY 6 COIL 131.8UH SMD |
1,278 | 4.99 |
|
Datasheet |
PM620 | 12-SMD, Gull Wing | Tape & Reel (TR) | Obsolete | 6 | 131.8 µH | 4.74 mH | ±20% | 7.68 A | 1.28 A | 480 mA | 80 mA | 16mOhm | 564mOhm | Unshielded | - | -40°C ~ 105°C | Surface Mount | 0.669" L x 0.843" W (17.00mm x 21.40mm) | 0.331" (8.40mm) |
