Gates and Inverters
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Logic Type | Number of Circuits | Number of Inputs | Features | Voltage - Supply | Current - Quiescent (Max) | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High | Max Propagation Delay @ V, Max CL | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SN74LVC1G02YEARIC GATE NOR 1CH 2-INP 5DSBGA |
2,565 | 0.19 |
|
Datasheet |
74LVC | 5-XFBGA, DSBGA | Tape & Reel (TR) | Obsolete | NOR Gate | 1 | 2 | - | 1.65V ~ 5.5V | 10 µA | 32mA, 32mA | 0.7V ~ 0.8V | 1.7V ~ 2V | 4ns @ 5V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 5-DSBGA (1.4x0.9) |
|
74HC1G32CME-EIC GATE OR 1CH 2-INP CMPAK-6 |
9,000 | 0.19 |
|
Datasheet |
74HC | 6-TSSOP, SC-88, SOT-363 | Bulk | Active | OR Gate | 1 | 2 | - | 2V ~ 6V | 20 µA | 2.6mA, 2.6mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V | 23ns @ 6V, 50pF | -40°C ~ 125°C | - | - | Surface Mount | CMPAK-6 |
|
MC74HCT14AFL1IC INVERTER SCM 4CH 2-INP 14SOIC |
9,000 | 0.19 |
|
Datasheet |
74HCT | 14-SOIC (0.209", 5.30mm Width) | Bulk | Active | Inverter | 4 | 2 | Schmitt Trigger | 4.5V ~ 5.5V | 1 µA | 4mA, 4mA | 0.5V ~ 0.6V | 1.9V ~ 2.1V | 32ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 14-SOIC |
|
74LVC3G06DP,125IC TRIPLE INVERTER O-D 8TSSOP |
8,029 | 0.25 |
|
Datasheet |
74LVC | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
MC74HC32AFL2IC GATE OR 4CH 2-INP 14SOIC |
8,000 | 0.19 |
|
Datasheet |
74HC | 14-SOIC (0.209", 5.30mm Width) | Bulk | Active | OR Gate | 4 | 2 | - | 2V ~ 6V | 1 µA | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V | 13ns @ 6V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 14-SOIC |
|
MC74HC86AFL2IC GATE XOR 4CH 2-INP 14SOIC |
8,000 | 0.19 |
|
Datasheet |
74HC | 14-SOIC (0.209", 5.30mm Width) | Bulk | Active | XOR (Exclusive OR) | 4 | 2 | - | 2V ~ 6V | 1 µA | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V | 17ns @ 6V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 14-SOIC |
|
CD4072BNSIC GATE OR 2CH 4-INP 14-SO |
7,569 | 0.19 |
|
Datasheet |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
NLV14001BDR2IC GATE NOR 4CH 2-INP 14-SOIC |
7,500 | 0.19 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
SN74LS133ML1IC NAND 13-INP |
6,000 | 0.19 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
74HCT2G32DC-Q100HIC GATE OR 2CH 2-INP 8VSSOP |
1,762 | 0.33 |
|
Datasheet |
74HCT | 8-VFSOP (0.091", 2.30mm Width) | Tape & Reel (TR) | Active | OR Gate | 2 | 2 | - | 4.5V ~ 5.5V | 1 µA | 4mA, 4mA | 0.8V | 2V | 24ns @ 4.5V, 50pF | -40°C ~ 125°C | Automotive | AEC-Q100 | Surface Mount | 8-VSSOP |
|
SN74ALS15ADRIC GATE AND |
5,000 | 0.19 |
|
Datasheet |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
MC74HC7266AFR1IC GATE XNOR 4CH 2-INP 14SOIC |
5,000 | 0.19 |
|
Datasheet |
74HC | 14-SOIC (0.209", 5.30mm Width) | Bulk | Active | XNOR (Exclusive NOR) | 4 | 2 | - | 2V ~ 6V | 2 µA | 5.2mA, 5.2mA | 0.3V ~ 1.2V | 1.5V ~ 4.2V | 20ns @ 6V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 14-SOIC |
|
|
74LVX14SJXIC INVERT SCHMITT 6CH 1INP 14SOP |
4,903 | 0.00 |
|
Datasheet |
74LVX | 14-SOIC (0.209", 5.30mm Width) | Bulk | Obsolete | Inverter | 6 | 1 | Schmitt Trigger | 2V ~ 3.6V | 2 µA | 4mA, 4mA | 0.9V | 2.2V | 14.1ns @ 3.3V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 14-SOP |
|
|
CD4073BNSIC GATE AND 3CH 3-INP 14-SO |
4,650 | 0.19 |
|
Datasheet |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
CD4002BNSIC GATE NOR 2CH 4-INP 14-SO |
4,400 | 0.19 |
|
Datasheet |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
MM74HCT00MXIC GATE NAND 4CH 2-INP 14SOIC |
4,116 | 0.63 |
|
Datasheet |
74HCT | 14-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Obsolete | NAND Gate | 4 | 2 | - | 4.5V ~ 5.5V | 1 µA | 4.8mA, 4.8mA | 0.8V | 2V | 23ns @ 5V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 14-SOIC |
|
74AUP2G32GT,115IC GATE OR 2CH 2-INP 8XSON |
2,294 | 0.08 |
|
Datasheet |
74AUP | 8-XFDFN | Tape & Reel (TR) | Active | OR Gate | 2 | 2 | - | 0.8V ~ 3.6V | 500 nA | 4mA, 4mA | 0.7V ~ 0.9V | 1.6V ~ 2V | 6.4ns @ 3.3V, 30pF | -40°C ~ 125°C | - | - | Surface Mount | 8-XSON, SOT833-1 (1.95x1) |
|
|
74LVQ02SCIC GATE NOR 4CH 2-INP 14SOIC |
4,272 | 0.00 |
|
Datasheet |
74LVQ | 14-SOIC (0.154", 3.90mm Width) | Tube | Obsolete | NOR Gate | 4 | 2 | - | 2V ~ 3.6V | 2 µA | 12mA, 12mA | 0.8V | 2V | 7.5ns @ 3.3V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 14-SOIC |
|
|
74VHCT08ANIC GATE AND 4CH 2-INP 14DIP |
4,000 | 0.00 |
|
Datasheet |
74VHCT | 14-DIP (0.300", 7.62mm) | Tube | Obsolete | AND Gate | 4 | 2 | - | 4.5V ~ 5.5V | 2 µA | 8mA, 8mA | 0.8V | 2V | 7.9ns @ 5V, 50pF | -40°C ~ 85°C | - | - | Through Hole | 14-DIP |
|
|
MC74F14MIC SCHMITT TRIGGER |
3,570 | 0.19 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
