Gate Drivers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Programmable | Driven Configuration | Channel Type | Number of Drivers | Gate Type | Voltage - Supply | Logic Voltage - VIL, VIH | Current - Peak Output (Source, Sink) | Input Type | High Side Voltage - Max (Bootstrap) | Rise / Fall Time (Typ) | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAX17602AUA+IC GATE DRVR LOW-SIDE 8UMAX |
587 | 2.30 |
|
Datasheet |
- | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | Tube | Active | Not Verified | Low-Side | Independent | 2 | N-Channel MOSFET | 4V ~ 14V | 0.8V, 2.1V | 4A, 4A | Inverting, Non-Inverting | - | 40ns, 25ns | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 8-uMAX-EP|8-uSOP-EP |
|
|
MAX17605AUA+IC GATE DRVR LOW-SIDE 8UMAX |
390 | 2.30 |
|
Datasheet |
- | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | Tube | Active | Not Verified | Low-Side | Independent | 2 | IGBT, SiC MOSFET | 4V ~ 14V | 2V, 4.25V | 4A, 4A | Inverting, Non-Inverting | - | 40ns, 25ns | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 8-uMAX-EP|8-uSOP-EP |
|
|
MAX17601AUA+IC GATE DRVR LOW-SIDE 8UMAX |
243 | 2.30 |
|
Datasheet |
- | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | Tube | Active | Not Verified | Low-Side | Independent | 2 | N-Channel MOSFET | 4V ~ 14V | 0.8V, 2.1V | 4A, 4A | Non-Inverting | - | 40ns, 25ns | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 8-uMAX-EP|8-uSOP-EP |
|
|
MAX17603AUA+IC GATE DRVR LOW-SIDE 8UMAX |
215 | 2.30 |
|
Datasheet |
- | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | Tube | Active | Not Verified | Low-Side | Independent | 2 | N-Channel MOSFET | 4V ~ 14V | 2V, 4.25V | 4A, 4A | Inverting | - | 40ns, 25ns | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 8-uMAX-EP|8-uSOP-EP |
|
TC4405CPAIC GATE DRVR LOW-SIDE 8DIP |
160 | 3.98 |
|
Datasheet |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | Not Verified | Low-Side | Independent | 2 | IGBT, N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 1.5A, 1.5A | Non-Inverting | - | 40ns, 40ns (Max) | 0°C ~ 70°C (TA) | - | - | Through Hole | 8-PDIP |
|
LM25101ASD-1/NOPBIC GATE DRVR HALF-BRIDGE 8WSON |
1,567 | 4.45 |
|
Datasheet |
- | 8-WDFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 2.3V, - | 3A, 3A | Non-Inverting | 100 V | 430ns, 260ns | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-WSON (4x4) |
|
ISL2101AABZIC GATE DRVR HALF-BRIDGE 8SOIC |
2,871 | 3.90 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tube | Active | Not Verified | Half-Bridge | Independent | 2 | N-Channel MOSFET | 9V ~ 14V | 1.4V, 2.2V | 2A, 2A | Non-Inverting | 114 V | 10ns, 10ns | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-SOIC |
|
MP1922GV-ZIC GATE DRVR HALF-BRIDGE 22QFN |
3,962 | 2.95 |
|
Datasheet |
- | 22-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | Half-Bridge | Independent | 2 | N-Channel MOSFET | 0V ~ 100V | 0.8V, 2.2V | 3A, 4A | Non-Inverting | 115 V | - | -40°C ~ 165°C (TJ) | - | - | Surface Mount | 22-QFN (4x5) |
|
|
TC4425VPAIC GATE DRVR LOW-SIDE 8DIP |
180 | 4.19 |
|
Datasheet |
- | 8-DIP (0.300", 7.62mm) | Tube | Active | Not Verified | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 3A, 3A | Inverting, Non-Inverting | - | 23ns, 25ns | -40°C ~ 150°C (TJ) | - | - | Through Hole | 8-PDIP |
|
ADP3635ARHZ-RLIC GATE DRVR LOW-SIDE 8MSOP |
3,621 | 3.12 |
|
Datasheet |
- | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | Tape & Reel (TR) | Active | Not Verified | Low-Side | Independent | 2 | N-Channel MOSFET | 9.5V ~ 18V | 0.8V, 2V | 4A, 4A | Inverting, Non-Inverting | - | 10ns, 10ns | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 8-MSOP-EP |
|
ADP3624ARDZ-RLIC GATE DRVR LOW-SIDE 8SOIC |
4,940 | 3.15 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) Exposed Pad | Tape & Reel (TR) | Active | Not Verified | Low-Side | Independent | 2 | N-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2V | 4A, 4A | Non-Inverting | - | 10ns, 10ns | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOIC-EP |
|
|
ADP3625ARDZ-RLIC GATE DRVR LOW-SIDE 8SOIC |
999 | 3.15 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) Exposed Pad | Tape & Reel (TR) | Active | Not Verified | Low-Side | Independent | 2 | N-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2V | 4A, 4A | Inverting, Non-Inverting | - | 10ns, 10ns | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOIC-EP |
|
MP6539BGV-PIC GATE DRVR HALF-BRIDGE 28VFQFN |
7,380 | 3.17 |
|
Datasheet |
- | 28-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | Half-Bridge | 3-Phase | 6 | N-Channel MOSFET | 8.5V ~ 14V | 0.8V, 2V | 800mA, 1A | Non-Inverting | 100 V | - | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 28-QFN (4x5) |
|
A4919GETTR-5-TIC GATE DRVR HI/LOW SIDE 28QFN |
2,975 | 3.06 |
|
Datasheet |
- | 28-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | High-Side or Low-Side | 3-Phase | 6 | N-Channel MOSFET | 5.5V ~ 50V | 0.8V, 1.5V | - | TTL | - | 35ns, 20ns | -40°C ~ 105°C (TA) | - | - | Surface Mount | 28-QFN (5x5) |
|
EL7252CSZIC GATE DRVR LOW-SIDE 8SOIC |
2,613 | 4.27 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tube | Active | Not Verified | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 16V | 0.8V, 2.4V | 2A, 2A | Inverting | - | 10ns, 10ns | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-SOIC |
|
A4919GLPTR-TIC GATE DRVR HI/LOW SIDE 28TSSOP |
4,000 | 3.34 |
|
Datasheet |
- | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad | Tape & Reel (TR) | Active | Not Verified | High-Side or Low-Side | 3-Phase | 6 | N-Channel MOSFET | 5.5V ~ 50V | 0.8V, 2V | - | TTL | - | 35ns, 20ns | -40°C ~ 105°C (TA) | - | - | Surface Mount | 28-TSSOP-EP |
|
LTC7067RMSE#PBFIC GATE DRVR HIGH-SIDE 12MSOP |
370 | 0.00 |
|
Datasheet |
- | 12-TSSOP (0.118", 3.00mm Width) Exposed Pad | Tube | Active | Not Verified | High-Side | Independent | 2 | N-Channel MOSFET | 5V ~ 14V | - | 3A, 3A | Non-Inverting | 15 V | 18ns, 14ns | -40°C ~ 150°C (TJ) | - | - | Surface Mount | 12-MSOP-EP |
|
|
MP1922GV-PIC GATE DRVR HALF-BRIDGE 22QFN |
500 | 3.37 |
|
Datasheet |
- | 22-VFQFN Exposed Pad | Tape & Reel (TR) | Active | Not Verified | Half-Bridge | Independent | 2 | N-Channel MOSFET | 0V ~ 100V | 0.8V, 2.2V | 3A, 4A | Non-Inverting | 115 V | - | -40°C ~ 165°C (TJ) | - | - | Surface Mount | 22-QFN (4x5) |
|
MAX4428CSA+IC GATE DRVR LOW-SIDE 8SOIC |
2,834 | 5.43 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tube | Active | Not Verified | Low-Side | Independent | 2 | N-Channel, P-Channel MOSFET | 4.5V ~ 18V | 0.8V, 2.4V | 1.5A, 1.5A | Inverting, Non-Inverting | - | 20ns, 20ns | 0°C ~ 70°C (TA) | - | - | Surface Mount | 8-SOIC |
|
|
A4919GLPTR-3-TIC GATE DRVR HI/LOW SIDE 28TSSOP |
4,000 | 3.65 |
|
Datasheet |
- | 28-TSSOP (0.173", 4.40mm Width) Exposed Pad | Tape & Reel (TR) | Active | Not Verified | High-Side or Low-Side | 3-Phase | 6 | N-Channel MOSFET | 5.5V ~ 50V | 0.8V, 2V | - | TTL | - | 35ns, 20ns | -40°C ~ 105°C (TA) | - | - | Surface Mount | 28-TSSOP-EP |
