Pulse Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TD01-1006KRLISO MOD AUI 100UH 16P THT |
2,696 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | Isolation and Data Interface (Encapsulated) | 100µH | - | 1:1 | Through Hole | 0.810" L x 0.300" W (20.57mm x 7.62mm) | 0.210" (5.33mm) | 0°C ~ 70°C | - | - |
|
|
20PT1024RX LFMDL LAN 10/100BT DIP |
3,677 | 1.54 |
|
- |
- | Tube | Active | - | - | - | - | - | - | - | - | - | - |
|
|
TG08-1205NSRLTRISO MOD T1 1C:2C 6P SMD T/R |
1,298 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1CT:2CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG10-1205NSRLTRISO MOD T1 1:1 6P SMD T/R |
2,459 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1:1:1 | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG42-1205NSRLTRISO MOD T1 1C:1.41C 6P SMD T/R |
3,401 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1CT:1.41CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG15-1205NSRLTRISO MOD T1 2C:1 6P SMD T/R |
4,629 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 2CT:1 | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG02-1205NSRLTRISO MOD T1 1C:1 6P SMD T/R |
3,942 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1CT:1 | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG70-1205NSRLTRISO MOD T1 1:1.36C 6P SMD T/R |
4,824 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1:1.36CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG04-1205NSRLTRISO MOD T1 1CH 1C:1C 6P SMD T/R |
3,296 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1CT:1CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG08-1205NSRLISO MOD T1 1C:2C 6P SMD |
1,006 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1CT:2CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG10-1205NSRLISO MOD T1 1:1 6P SMD |
2,144 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1:1:1 | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG42-1205NSRLISO MOD T1 1C:1.41C 6P SMD |
2,703 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1CT:1.41CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG70-1205NSRLISO MOD T1 1:1.36C 6P SMD |
2,085 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1:1.36CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG15-1205NSRLISO MOD T1 2C:1 6P SMD |
1,315 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 2CT:1 | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG02-1205NSRLISO MOD T1 1C:1 6P SMD |
3,321 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1CT:1 | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG04-1205NSRLISO MOD T1 1CH 1C:1C 6P SMD |
3,659 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | T1/E1 (Single) | 1.2mH | - | 1CT:1CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
SM75056PELPULSE XFMR 1:1 TX 1:1 RX 1.2MH |
3,335 | 1.55 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | 1.2mH | - | 1:1 Transmitter, 1:1 Receiver | Surface Mount | 0.504" L x 0.272" W (12.80mm x 6.90mm) | 0.222" (5.65mm) | -40°C ~ 85°C | - | - |
|
|
TG74-1406N1RLTRISO MOD 10BASE-T 1C:2C X-TEMP |
4,699 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10 Base-T | 140µH | - | 1CT:1CT Transmitter, 1CT:2CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | -40°C ~ 85°C | - | - |
|
|
TG04-2006N1LFTRISO MOD 10BASE-T 1C:1C X-TEMP |
4,489 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10 Base-T | 200µH | - | 1CT:1CT Transmitter, 1CT:1CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | -40°C ~ 85°C | - | - |
|
|
TG42-1406N1RLTRISO MOD T1 1C:1.41C 16P SMD T/R |
3,348 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10 Base-T | 140µH | - | 1CT:1CT Transmitter, 1CT:1.41CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
