RF Power Dividers/Splitters
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Insertion Loss | Frequency | Specifications | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PE20DV12002 way N Power Divider from 216 M |
1,025 | 0.00 |
|
Datasheet |
Module | - | Retail Package | Active | 0.15dB | 216 MHz ~ 450 MHz | Isolation (Min) 22dB, 2° Imbalance (Max), 1.3 VSWR (Max) | 2.992" L x 2.362" W x 0.807" H (76.00mm x 60.00mm x 20.50mm) |
|
|
WM4PD-2-18.5-SPOWER DIV 4 WAY 2-18.5 GHZ SMA |
1,101 | 0.00 |
|
Datasheet |
Module, SMA Connectors | Wilkinson Dividers/Splitters | Retail Package | Active | 0.9dB | 2 GHz ~ 18.5 GHz | Isolation (Typ) 20dB, Return Loss (Typ) 15dB, Imbalance (Typ) 3° | 3.000" L x 2.000" W x 0.380" H (76.20mm x 50.80mm x 9.70mm) |
|
|
WMRD09-7.2-SPOWER DIV 9 WAY 0HZ-7.2GHZ SMA |
3,020 | 0.00 |
|
Datasheet |
Module, SMA Connectors | Resistive Dividers/Splitters | Retail Package | Active | 19dB | 0 GHz ~ 7.2 GHz | Isolation (Typ) 28.5dB, Return Loss (Typ) 14dB | 1.750" L x 1.750" W x 0.550" H (44.50mm x 25.40mm x 13.90mm) |
|
|
PE20702 Way SMA Power Divider From 2 M |
1,103 | 0.00 |
|
Datasheet |
Module, SMA Connectors | - | Retail Package | Active | 1dB | 2 MHz ~ 500 MHz | Isolation (Min) 25dB, 2° Imbalance (Max), 1.35 VSWR (Max) | 1.760" L x 1.673" W x 0.943" H (44.70mm x 42.50mm x 23.95mm) |
|
|
PE20014 Way BNC Power Divider From 2 M |
2,143 | 0.00 |
|
Datasheet |
Module, SMA Connectors | - | Retail Package | Active | 1.5dB | 2 MHz ~ 500 MHz | Isolation (Min) 22dB, 3° Imbalance (Max), 1.25 VSWR (Max) | 3.445" L x 1.744" W x 0.939" H (87.50mm x 44.30mm x 23.85mm) |
|
|
PE20214 Way SMA Wilkinson Power Divide |
1,058 | 0.00 |
|
Datasheet |
Module, SMA Connectors | - | Retail Package | Active | 1dB | 7 GHz ~ 12.4 GHz | Isolation (Min) 16dB, 6° Imbalance (Max), 1.55 VSWR (Max) | 2.750" L x 1.280" W x 0.500" H (69.85mm x 32.51mm x 12.70mm) |
|
|
PE20094 Way SMA Wilkinson Power Divide |
2,149 | 0.00 |
|
Datasheet |
Module, SMA Connectors | - | Retail Package | Active | 0.4dB | 500 MHz ~ 1 GHz | Isolation (Min) 20dB, 1.3 VSWR (Max) | 2.500" L x 2.500" W x 0.424" H (63.50mm x 63.50mm x 10.77mm) |
|
|
PE20442 Way N Power Divider From 2 MHz |
1,396 | 0.00 |
|
Datasheet |
Module | - | Retail Package | Active | 1dB | 2 MHz ~ 500 MHz | Isolation (Min) 25dB, 1.35 VSWR (Max) | 1.752" L x 1.669" W x 0.949" H (44.50mm x 42.40mm x 24.11mm) |
|
|
WM3PD-2-18-SPOWER DIV 3 WAY 2-18GHZ SMA |
2,797 | 0.00 |
|
Datasheet |
Module, SMA Connectors | Wilkinson Dividers/Splitters | Retail Package | Active | 0.8dB | 2 GHz ~ 18 GHz | Isolation (Typ) 22dB, Return Loss (Typ) 16dB, Imbalance (Typ) 3° | 4.460" L x 2.460" W x 0.380" H (113.30mm x 62.50mm x 9.70mm) |
|
|
WMRD10-7.2-SPOWER DIV 10 WAY 0HZ-7.2GHZ SMA |
3,926 | 0.00 |
|
Datasheet |
Module, SMA Connectors | Resistive Dividers/Splitters | Retail Package | Active | 20dB | 0 GHz ~ 7.2 GHz | Isolation (Typ) 34dB, Return Loss (Typ) 14dB | 1.750" L x 1.750" W x 0.550" H (44.50mm x 25.40mm x 13.90mm) |
|
|
WM4PD-0.5-18-SPOWER DIV 4 WAY 0.5-18 GHZ SMA |
2,237 | 0.00 |
|
Datasheet |
Module, SMA Connectors | Wilkinson Dividers/Splitters | Retail Package | Active | 2.5dB | 500 MHz ~ 18 GHz | Isolation (Typ) 20dB, Return Loss (Typ) 18dB, Imbalance (Typ) 2° | 6.250" L x 2.980" W x 0.500" H (158.80mm x 75.70mm x 12.70mm) |
|
|
PE20642 Way 2.92mm Resistive Power Div |
3,474 | 0.00 |
|
Datasheet |
SMA In-Line Module | - | Retail Package | Active | 7.5dB | 0 Hz ~ 18 GHz | 3° Imbalance (Max), 1.3 VSWR (Max) | 3.440" L x 1.750" W x 0.930" H (87.38mm x 44.45mm x 23.62mm) |
|
PE20032 Way BNC Power Divider from 10 |
2,670 | 0.00 |
|
Datasheet |
Module | - | Retail Package | Active | 1.5dB | 10 MHz ~ 1 GHz | Isolation (Min) 20dB, 3° Imbalance (Max), 1.5 VSWR (Max) | 1.752" L x 1.669" W x 0.939" H (44.50mm x 42.40mm x 23.85mm) |
|
|
PE20DV12128 way SMA Power Divider from 500 |
1,926 | 0.00 |
|
Datasheet |
Module, SMA Connectors | - | Retail Package | Active | 0.5dB | 500 MHz ~ 1 GHz | Isolation (Min) 20dB, 5° Imbalance (Max), 1.35 VSWR (Max) | 4.500" L x 3.000" W x 0.520" H (114.30mm x 76.20mm x 13.20mm) |
|
|
WM2PD-2-26.5-SPOWER DIV 2 WAY 2-26.5GHZ SMA |
2,409 | 0.00 |
|
Datasheet |
Module, SMA Connectors | - | Retail Package | Active | 0.7dB | 2 GHz ~ 26.5 GHz | Isolation (Typ) 20dB, Return Loss (Typ) 20dB, Imbalance (Typ) 1.5° | 1.790" L x 1.040" W x 0.500" H (45.5mm x 26.4mm x 12.7mm) |
|
|
PE20352 Way N Wilkinson Power Divider |
4,592 | 0.00 |
|
Datasheet |
Module | - | Retail Package | Active | 0.7dB | 4 GHz ~ 8 GHz | Isolation (Min) 20dB, 1.3 VSWR (Max) | 2.000" L x 1.000" W x 1.050" H (50.80mm x 25.40mm x 26.67mm) |
|
|
PE20S00238 Way SMA Power Divider From 500 |
4,333 | 0.00 |
|
Datasheet |
Module, SMA Connectors | - | Retail Package | Active | 1.5dB | 500 MHz ~ 2 GHz | Isolation (Min) 20dB, 17dB Return Loss, 4° Imbalance (Max), 1.4 VSWR (Max) | 4.252" L x 4.055" W x 0.394" H (108.00mm x 103.00mm x 10.00mm) |
|
|
PE20DV11434 Way N Female Input Connector P |
1,327 | 0.00 |
|
Datasheet |
Module | - | Retail Package | Active | 0.1dB | 800 MHz ~ 2.5 GHz | Isolation (Typ) 6dB, 1.25 VSWR (Max) | 9.291" L x 0.984" W x 1.004" H (236.00mm x 25.00mm x 25.50mm) |
|
|
PE20DV11848 Way SMA Power Divider From 2 G |
4,924 | 0.00 |
|
Datasheet |
Module, SMA Connectors | - | Retail Package | Active | 0.6dB | 2 GHz ~ 4 GHz | Isolation (Min) 20dB, 5° Imbalance (Max), 1.3 VSWR (Max) | 4.252" L x 2.480" W x 0.413" H (108.00mm x 63.00mm x 10.50mm) |
|
|
PE20DV11838 Way SMA Power Divider From 2 G |
3,640 | 0.00 |
|
Datasheet |
Module, SMA Connectors | - | Retail Package | Active | 0.6dB | 2 GHz ~ 4 GHz | Isolation (Min) 20dB, 5° Imbalance (Max), 1.3 VSWR (Max) | 4.252" L x 2.480" W x 0.413" H (108.00mm x 63.00mm x 10.50mm) |
