Arrays, Signal Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Number of Coils | Inductance - Connected In Parallel | Inductance - Connected In Series | Tolerance | Current Rating - Parallel | Current Rating - Series | Current Saturation - Parallel | Current Saturation - Series | DC Resistance (DCR) - Parallel | DC Resistance (DCR) - Series | Shielding | Ratings | Operating Temperature | Mounting Type | Size / Dimension | Height |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
P0395NLTINDUCT ARRAY 2 COIL 2.2UH SMD |
1,097 | 1.59 |
|
Datasheet |
Tomcat | Nonstandard | Tape & Reel (TR) | Active | 2 | 2.2 µH | 9 µH | ±20% | 14.4 A | 7.2 A | - | - | 4.41mOhm | 17.6mOhm | Unshielded | - | -40°C ~ 130°C | Surface Mount | 0.715" L x 0.590" W (18.16mm x 14.99mm) | 0.310" (7.87mm) |
|
P0402NLINDUCT ARRAY 2 COIL 40.5UH SMD |
555 | 3.09 |
|
Datasheet |
Tomcat | Nonstandard | Tube | Active | 2 | 40.5 µH | 161.8 µH | ±20% | 3.54 A | 1.77 A | - | - | 53.21mOhm | 212.8mOhm | Unshielded | - | -40°C ~ 130°C | Surface Mount | 0.715" L x 0.590" W (18.16mm x 14.99mm) | 0.310" (7.87mm) |
|
7448991100SMT MOLDED COUPLED INDUCTOR SIZE |
696 | 3.72 |
|
Datasheet |
WE-MCRI | Nonstandard | Tape & Reel (TR) | Active | 2 | 10 µH | - | ±20% | 3.7 A | - | 9.8 A | - | 62mOhm | - | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.453" L x 0.394" W (11.50mm x 10.00mm) | 0.161" (4.10mm) |
|
P0176NLINDUCT ARRAY 2 COIL 5.5UH SMD |
550 | 5.72 |
|
Datasheet |
Polecat | Nonstandard | Tube | Active | 2 | 5.5 µH | 22.45 µH | ±10% | 5.2 A | 2.6 A | - | - | 19mOhm Max | 76mOhm Max | Unshielded | - | -40°C ~ 130°C | Surface Mount | 0.500" L x 0.500" W (12.70mm x 12.70mm) | 0.215" (5.46mm) |
|
|
P0176NLTINDUCT ARRAY 2 COIL 5.5UH SMD |
380 | 3.01 |
|
Datasheet |
Polecat | Nonstandard | Tape & Reel (TR) | Active | 2 | 5.5 µH | 22.45 µH | ±10% | 5.2 A | 2.6 A | - | - | 19mOhm Max | 76mOhm Max | Unshielded | - | -40°C ~ 130°C | Surface Mount | 0.500" L x 0.500" W (12.70mm x 12.70mm) | 0.215" (5.46mm) |
|
LCP5-3.00-22INDUCT ARRAY 2 COIL 22UH SMD |
300 | 3.73 |
|
Datasheet |
LCP | Nonstandard | Tape & Reel (TR) | Active | 2 | 22 µH | 88 µH | ±15% | 3 A | 1.5 A | - | - | 38mOhm | 152mOhm | Unshielded | - | -40°C ~ 125°C | Surface Mount | 0.472" L x 0.472" W (12.00mm x 12.00mm) | 0.358" (9.10mm) |
|
|
ERUC23-3R2KSMT FLAT WIRE COUPLED INDUCTOR, |
537 | 0.00 |
|
Datasheet |
ERUC23 | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | 2 | 5.9 µH | - | ±10% | - | - | 57.5 A | 28.75 A | - | - | Unshielded | - | -40°C ~ 150°C | Surface Mount | 1.055" L x 0.543" W (26.80mm x 13.80mm) | 0.551" (14.00mm) |
|
|
ERUC23-2R8KSMT FLAT WIRE COUPLED INDUCTOR, |
516 | 0.00 |
|
Datasheet |
ERUC23 | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | 2 | 5.4 µH | - | ±10% | - | - | 55 A | 27.5 A | 1.25mOhm | 1.25mOhm | Unshielded | - | -40°C ~ 150°C | Surface Mount | 1.055" L x 0.543" W (26.80mm x 13.80mm) | 0.555" (14.10mm) |
|
|
ERUC23-1R8KSMT FLAT WIRE COUPLED INDUCTOR, |
498 | 0.00 |
|
Datasheet |
ERUC23 | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | 2 | 3.5 µH | 14 µH | ±10% | - | - | 73 A | 36.5 A | - | - | Unshielded | - | -40°C ~ 150°C | Surface Mount | 1.055" L x 0.543" W (26.80mm x 13.80mm) | 0.563" (14.30mm) |
|
|
ERUC23-2R2KSMT FLAT WIRE COUPLED INDUCTOR, |
496 | 0.00 |
|
Datasheet |
ERUC23 | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | 2 | 4.1 µH | - | ±10% | - | - | 71 A | 35.5 A | 1.25mOhm | 1.25mOhm | Unshielded | - | -40°C ~ 150°C | Surface Mount | 1.055" L x 0.543" W (26.80mm x 13.80mm) | 0.555" (14.10mm) |
|
|
ERUC23-4R1KSMT FLAT WIRE COUPLED INDUCTOR, |
181 | 0.00 |
|
Datasheet |
ERUC23 | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | 2 | 7.9 µH | 31.6 µH | ±10% | - | - | 45 A | 22.5 A | - | - | Unshielded | - | -40°C ~ 150°C | Surface Mount | 1.055" L x 0.543" W (26.80mm x 13.80mm) | 0.551" (14.00mm) |
|
|
SMT45A-801LFINDUCT ARRAY 2 COIL 8UH SMD |
549 | 0.00 |
|
Datasheet |
SMT45A | Nonstandard | Tape & Reel (TR) | Active | 2 | 8 µH | 32 µH | ±25% | 5.49 A | 2.74 A | 4.5 A | 2.25 A | 13mOhm | 50.2mOhm | Unshielded | - | -55°C ~ 125°C | Surface Mount | 0.480" L x 0.480" W (12.20mm x 12.20mm) | 0.250" (6.35mm) |
|
|
SMT45A-203INDUCT ARRAY 2 COIL 200UH SMD |
590 | 0.00 |
|
Datasheet |
SMT45A | Nonstandard | Tape & Reel (TR) | Active | 2 | 200 µH | 800 µH | ±25% | 920 mA | 460 mA | 940 mA | 470 mA | 447mOhm | 1.79Ohm | Unshielded | - | -55°C ~ 125°C | Surface Mount | 0.480" L x 0.480" W (12.20mm x 12.20mm) | 0.250" (6.35mm) |
|
|
DRQ73-1R0-RINDUCT ARRAY 2 COIL 992NH SMD |
2,660 | 1.03 |
|
Datasheet |
DRQ | Nonstandard | Tape & Reel (TR) | Active | 2 | 992 nH | 3.968 µH | ±20% | 5.25 A | 2.63 A | 7.97 A | 3.99 A | 10.3mOhm | 41.1mOhm | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.299" L x 0.299" W (7.60mm x 7.60mm) | 0.140" (3.55mm) |
|
|
DRQ73-331-RINDUCT ARRAY 2 COIL 325.5UH SMD |
4,457 | 1.03 |
|
Datasheet |
DRQ | Nonstandard | Tape & Reel (TR) | Active | 2 | 325.5 µH | 1.302 mH | ±20% | 420 mA | 211 mA | 440 mA | 220 mA | 1.59Ohm | 6.36Ohm | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.299" L x 0.299" W (7.60mm x 7.60mm) | 0.140" (3.55mm) |
|
DRQ74-331-RINDUCT ARRAY 2 COIL 335.6UH SMD |
1,305 | 1.07 |
|
Datasheet |
DRQ | Nonstandard | Tape & Reel (TR) | Active | 2 | 335.6 µH | 1.342 mH | ±20% | 450 mA | 224 mA | 540 mA | 270 mA | 1.41Ohm | 5.66Ohm | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.299" L x 0.299" W (7.60mm x 7.60mm) | 0.175" (4.45mm) |
|
|
DRQ125-102-RINDUCT ARRAY 2 COIL 1.008MH SMD |
4,153 | 1.24 |
|
Datasheet |
DRQ | Nonstandard | Tape & Reel (TR) | Active | 2 | 1.008 mH | 4.032 mH | ±20% | 570 mA | 283 mA | 700 mA | 350 mA | 1.69Ohm | 6.76Ohm | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.236" (6.00mm) |
|
HM78D-7556R8MLFTRINDUCT ARRAY 2 COIL 6.8UH SMD |
955 | 1.45 |
|
Datasheet |
HM78D | Nonstandard | Cut Tape (CT) | Discontinued at Digi-Key | 2 | 6.8 µH | 29.38 µH | ±20% | 2.6 A | 1.3 A | 3.67 A | 1.84 A | 41.8mOhm | 167mOhm | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.303" L x 0.303" W (7.70mm x 7.70mm) | 0.189" (4.80mm) |
|
|
HM78D-755151MLFTRINDUCT ARRAY 2 COIL 150UH SMD |
918 | 1.45 |
|
Datasheet |
HM78D | Nonstandard | Cut Tape (CT) | Discontinued at Digi-Key | 2 | 150 µH | 600 µH | ±20% | 690 mA | 346 mA | 810 mA | 410 mA | 591mOhm | 2.37Ohm | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.303" L x 0.303" W (7.70mm x 7.70mm) | 0.189" (4.80mm) |
|
HM78D-755331MLFTRINDUCT ARRAY 2 COIL 330UH SMD |
881 | 1.45 |
|
Datasheet |
HM78D | Nonstandard | Cut Tape (CT) | Discontinued at Digi-Key | 2 | 330 µH | 1.342 mH | ±20% | 450 mA | 224 mA | 540 mA | 270 mA | 1.41Ohm | 5.66Ohm | Shielded | - | -40°C ~ 125°C | Surface Mount | 0.303" L x 0.303" W (7.70mm x 7.70mm) | 0.189" (4.80mm) |
