Audio Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Turns Ratio - Primary:Secondary | Impedance - Primary (Ohms) | Impedance - Secondary (Ohms) | DC Resistance (DCR) - Primary | DC Resistance (DCR) - Secondary | Transformer Type | Frequency Range | Frequency Response | Voltage - Isolation | Insertion Loss | Return Loss | Power Level | Operating Temperature | Approval Agency | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
106RAUDIO XFMR 48CT / 8 TH |
1,378 | 32.88 |
|
Datasheet |
106 | Bulk | Active | - | 48CT | 8 | 2.4Ohm | 700mOhm | Miniature Epoxy Potted | 170Hz | -1dB | 200V | 1dB | - | 1.5W | - | - | Through Hole | 1.080" L x 0.880" W (27.43mm x 22.35mm) | 0.950" (24.13mm) | PC Pin |
|
|
106GAUDIO XFMR 4K / 600CT TH |
4,720 | 30.70 |
|
Datasheet |
106 | Bulk | Active | - | 4k | 600CT | 340Ohm | 24Ohm | Miniature Epoxy Potted | 215Hz | -1dB | 200V | 1dB | - | 150mW | - | - | Through Hole | 1.080" L x 0.880" W (27.43mm x 22.35mm) | 0.950" (24.13mm) | PC Pin |
|
|
106MAUDIO XFMR 20K / 2KCT TH |
4,464 | 30.70 |
|
Datasheet |
106 | Bulk | Active | - | 20k | 2kCT | 1.18kOhm | 89Ohm | Miniature Epoxy Potted | 215Hz | -1dB | 200V | 1dB | - | 150mW | - | - | Through Hole | 1.080" L x 0.880" W (27.43mm x 22.35mm) | 0.950" (24.13mm) | PC Pin |
|
117E8AUDIO XFMR 3.2 / 70V CHAS MNT |
3,159 | 30.70 |
|
Datasheet |
117 | Bulk | Active | - | 3.2 | 70V | - | - | Sound Distribution | 100Hz ~ 9kHz | 1dB | - | 2dB | - | 8W | - | - | Chassis Mount | 3.250" L x 1.750" W (82.55mm x 44.45mm) | 2.000" (50.80mm) | Solder Lug |
|
|
117J8AUDIO XFMR 3.2 / 25V CHAS MNT |
1,405 | 31.80 |
|
Datasheet |
117 | Bulk | Active | - | 3.2 | 25V | - | - | Sound Distribution | 100Hz ~ 9kHz | 1dB | - | 2dB | - | 8W | - | - | Chassis Mount | 3.250" L x 1.750" W (82.55mm x 44.45mm) | 2.000" (50.80mm) | Solder Lug |
|
6W68HFAUDIO XFMR |
4,546 | 0.00 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
106WAUDIO XFMR 500CT / 3.2 TH |
1,519 | 32.88 |
|
Datasheet |
106 | Bulk | Active | - | 500CT | 3.2 | 26Ohm | 300mOhm | Miniature Epoxy Potted | 170Hz | -1dB | 200V | 1dB | - | 1.5W | - | - | Through Hole | 1.080" L x 0.880" W (27.43mm x 22.35mm) | 0.950" (24.13mm) | PC Pin |
|
143JAUDIO XFMR 3K / 1KCT CHAS MNT |
4,956 | 37.00 |
|
Datasheet |
143 | Bulk | Active | - | 3k | 1kCT | 265Ohm | 53Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
143HAUDIO XFMR 1.5K / 500CT CHAS MNT |
3,224 | 37.00 |
|
Datasheet |
143 | Bulk | Active | - | 1.5k | 500CT | 111Ohm | 24Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
143BAUDIO XFMR 3.2 / 4K CHAS MNT |
4,252 | 37.00 |
|
Datasheet |
143 | Bulk | Active | - | 3.2 | 4k | 400mOhm | 245Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 15mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
143NAUDIO XFMR 10K / 2KCT CHAS MNT |
2,587 | 37.00 |
|
Datasheet |
143 | Bulk | Active | - | 10k | 2kCT | 720Ohm | 89Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
143LAUDIO XFMR 10K / 200CT CHAS MNT |
3,180 | 0.00 |
|
Datasheet |
143 | Bulk | Active | - | 10k | 200CT | 720Ohm | 9Ohm | Economical Open Type | 150Hz ~ 15kHz | ±1dB | - | - | - | 30mW | - | - | Chassis Mount | 1.000" L x 0.690" W (25.40mm x 17.53mm) | 0.690" (17.53mm) | Wire Leads |
|
|
1140-LU-BAUDIO XFMR 600 / 600 CHAS MNT |
3,141 | 0.00 |
|
Datasheet |
1140 | Bulk | Active | 1:1 | 600 | 600 | 58Ohm | 58Ohm | Line (Audio Power Distribution) | 20Hz ~ 20kHz | - | 250V | - | - | - | - | - | Chassis Mount | 1.450" L x 1.063" W (36.83mm x 27.00mm) | 1.190" (30.23mm) | Wire Leads |
|
|
1750BBTRANSFORMERS/FILTERS/FERRITE |
1,164 | 0.00 |
|
- |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
6K112HFAUDIO XFMR |
3,399 | 0.00 |
|
- |
- | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
T-050100TBALUNS |
4,504 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
1750PAAUDIO XFMR 4, 8, 16 CHAS MNT |
3,322 | 0.00 |
|
Datasheet |
1750 | Bulk | Active | - | - | 4, 8, 16 | - | - | Push-Pull Audiophile, Ultra-Linear - Tube Output | 70Hz ~ 15kHz | - | 1500V | - | - | - | -40°C ~ 105°C | - | Chassis Mount | - | - | Wire Leads |
|
|
1140-LU-DAUDIO XFMR 600 / 600 CHAS MNT |
2,101 | 0.00 |
|
Datasheet |
1140 | Bulk | Active | 1:1 | 600 | 600 | 40Ohm | 40Ohm | Line (Audio Power Distribution) | 20Hz ~ 20kHz | - | 250V | - | - | - | - | - | Chassis Mount | 1.700" L x 1.190" W (43.18mm x 30.23mm) | 1.380" (35.05mm) | Wire Leads |
|
|
124FAUDIO XFMR CHAS MNT |
3,537 | 0.00 |
|
Datasheet |
124 | Bulk | Active | - | - | - | 900Ohm | - | Tube Driver and Speaker Matching | 150Hz ~ 15kHz | - | 500Vrms | - | - | 5W | - | - | Chassis Mount | - | 2.370" (60.20mm) | Wire Leads |
|
|
1750SAUDIO XFMR 5.1K / 8 CHAS MNT |
2,384 | 0.00 |
|
Datasheet |
175 | Bulk | Active | - | 5.1k | 8 | 380Ohm | 750mOhm | Push-Pull Audiophile, Ultra-Linear - Tube Output | 50Hz ~ 12kHz | -4dB | 1500V | - | - | 25W | -40°C ~ 105°C | - | Chassis Mount | 3.125" L x 2.120" W (79.38mm x 53.85mm) | 2.308" (58.62mm) | Wire Leads |
