Fixed Inductors
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Type | Material - Core | Inductance | Tolerance | Current Rating (Amps) | Current - Saturation (Isat) | Shielding | DC Resistance (DCR) | Q @ Freq | Frequency - Self Resonant | Ratings | Operating Temperature | Inductance Frequency - Test | Features | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
L0806C220KPWITL0806C220KPWIT |
1,330 | 0.08 |
|
Datasheet |
L-PWI | 0806 (2016 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 22 µH | ±10% | 165 mA | - | Unshielded | 1.8Ohm | - | 16MHz | - | -40°C ~ 105°C | 2.52 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.071" (1.80mm) |
|
|
L0805C101KDWSTL0805C101KDWST |
1,511 | 0.12 |
|
Datasheet |
L-DWS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 100 µH | ±10% | 130 mA | 60mA | Unshielded | 7Ohm | - | 8MHz | - | -40°C ~ 105°C | 796 kHz | - | Surface Mount | 0805 | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.057" (1.45mm) |
|
|
L0805C100KPWITL0805C100KPWIT |
2,563 | 0.08 |
|
Datasheet |
L-PWI | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 10 µH | ±10% | 200 mA | - | Unshielded | 1.2Ohm | - | 40MHz | - | -40°C ~ 105°C | 2.52 MHz | - | Surface Mount | 0805 | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.057" (1.45mm) |
|
|
L0805C101KPWSTL0805C101KPWST |
3,284 | 0.07 |
|
Datasheet |
L-PWS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 100 µH | ±10% | 30 mA | - | Unshielded | 7Ohm | - | 8MHz | - | -40°C ~ 105°C | 796 kHz | - | Surface Mount | 0805 | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.057" (1.45mm) |
|
|
L0805C2R2MDWSTL0805C2R2MDWST |
3,733 | 0.12 |
|
Datasheet |
L-DWS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 2.2 µH | ±20% | 770 mA | 410mA | Unshielded | 230mOhm | - | 80MHz | - | -40°C ~ 105°C | 7.96 MHz | - | Surface Mount | 0805 | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.057" (1.45mm) |
|
|
L1207C4R7MPWSTL1207C4R7MPWST |
3,810 | 0.08 |
|
Datasheet |
L-PWS | 1207 (3218 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 4.7 µH | ±20% | 550 mA | - | Unshielded | 130mOhm | - | 41MHz | - | -40°C ~ 105°C | 7.96 MHz | - | Surface Mount | 1207 | 0.126" L x 0.071" W (3.20mm x 1.80mm) | 0.079" (2.00mm) |
|
|
L1007C150KDWITL1007C150KDWIT |
2,854 | 0.11 |
|
Datasheet |
L-DWI | 1007 (2518 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 15 µH | ±10% | 500 mA | 350mA | Unshielded | 845mOhm Max | - | 23MHz | - | -40°C ~ 105°C | 2.52 MHz | - | Surface Mount | 1007 | 0.098" L x 0.071" W (2.50mm x 1.80mm) | 0.079" (2.00mm) |
|
|
L0805C470MDWSTL0805C470MDWST |
1,840 | 0.12 |
|
Datasheet |
L-DWS | 0805 (2012 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 47 µH | ±20% | 190 mA | 90mA | Unshielded | 3.7Ohm | - | 11MHz | - | -40°C ~ 105°C | 2.52 MHz | - | Surface Mount | 0805 | 0.079" L x 0.049" W (2.00mm x 1.25mm) | 0.057" (1.45mm) |
|
|
L3010C2R2MDWDTL3010C2R2MDWDT |
3,637 | 0.32 |
|
Datasheet |
L-DWD | 1212 (3030 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 2.2 µH | ±20% | 1.1 A | - | Shielded | 95mOhm | - | 82MHz | - | -25°C ~ 120°C | 100 kHz | - | Surface Mount | 1212 | 0.118" L x 0.118" W (3.00mm x 3.00mm) | 0.039" (1.00mm) |
|
|
L1207C680MPWSTL1207C680MPWST |
3,665 | 0.08 |
|
Datasheet |
L-PWS | 1207 (3218 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | - | 68 µH | ±20% | 145 mA | - | Unshielded | 1.49Ohm | - | 11MHz | - | -40°C ~ 105°C | 2.52 MHz | - | Surface Mount | 1207 | 0.126" L x 0.071" W (3.20mm x 1.80mm) | 0.079" (2.00mm) |
|
|
L0806C220MDWITL0806C220MDWIT |
2,417 | 0.11 |
|
Datasheet |
L-DWI | 0806 (2016 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | Ferrite | 22 µH | ±20% | 240 mA | 250mA | Unshielded | 1.8Ohm | - | 16MHz | - | -40°C ~ 105°C | 2.52 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.071" (1.80mm) |
|
|
L0806C220KDWITL0806C220KDWIT |
4,090 | 0.11 |
|
Datasheet |
L-DWI | 0806 (2016 Metric) | Tape & Reel (TR) | Obsolete | Wirewound | Ferrite | 22 µH | ±10% | 240 mA | 250mA | Unshielded | 1.8Ohm | - | 16MHz | - | -40°C ~ 105°C | 2.52 MHz | - | Surface Mount | 0806 | 0.079" L x 0.063" W (2.00mm x 1.60mm) | 0.071" (1.80mm) |
|
|
NTT501ADNLTNTT501ADNLT |
4,198 | 0.00 |
|
- |
- | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
BSPQ0004020314NH00FIXED IND 14NH SMD |
3,722 | 0.06 |
|
Datasheet |
BSPQ | 01005 (0402 Metric) | Tape & Reel (TR) | Active | Thin Film | Ceramic | 14 nH | ±3% | 190 mA | - | Unshielded | 1.26Ohm Max | 13 @ 500MHz | 4GHz | - | -55°C ~ 125°C | 500 MHz | - | Surface Mount | 1005 | 0.016" L x 0.008" W (0.40mm x 0.20mm) | 0.013" (0.32mm) |
|
FWPQ2817H-330K33uH+/-10% Flat Wire Pwr Induct. |
1,016 | 6.50 |
|
Datasheet |
FWTPQ2817H | 2-SMD, Gull Wing | Tray | Active | Wirewound | - | 33 µH | ±10% | 28 A | 9.6A | Shielded | 2.82mOhm Max | - | 10MHz | - | -40°C ~ 85°C | 500 kHz | - | Surface Mount | 2-SMD | 1.102" L x 0.760" W (28.00mm x 19.30mm) | 0.669" (17.00mm) |
|
|
PCI30-151M-RC150uH +/-20% SMD Power Inductor |
4,915 | 0.00 |
|
Datasheet |
PCI30 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 150 µH | ±20% | - | 740mA | Unshielded | 940mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.118" (3.00mm) |
|
|
PCI30-331M-RC330uH +/-20% SMD Power Inductor |
4,528 | 0.00 |
|
Datasheet |
PCI30 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 330 µH | ±20% | 500 mA | - | Unshielded | 2.15Ohm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.510" L x 0.370" W (12.95mm x 9.40mm) | 0.118" (3.00mm) |
|
|
SQAC0806-19NG-RC19nH +/-2% Square Wound Coil |
2,894 | 0.00 |
|
Datasheet |
SQAC0806 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | Air | 19.4 nH | ±2% | 2.9 A | - | Unshielded | 10mOhm Max | 90 @ 400MHz | 4GHz | - | -40°C ~ 125°C | 400 MHz | - | Surface Mount | - | 0.102" L x 0.072" W (2.59mm x 1.83mm) | 0.059" (1.50mm) |
|
|
RDC40-151K-RC150uH +/-10% Radial Drum Core |
3,885 | 0.00 |
|
Datasheet |
RDC40 | Radial, Vertical Cylinder | Tape & Reel (TR) | Active | Drum Core | - | 150 µH | ±10% | 11.4 A | 16.4A | Unshielded | 40mOhm Max | - | - | - | -55°C ~ 125°C | - | - | Through Hole | Radial | 1.500" Dia (38.10mm) | 1.030" (26.16mm) |
|
|
RLH9012-331KLRADIAL INDUCTORS |
1,746 | 0.00 |
|
- |
- | - | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
