Gates and Inverters
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Logic Type | Number of Circuits | Number of Inputs | Features | Voltage - Supply | Current - Quiescent (Max) | Current - Output High, Low | Input Logic Level - Low | Input Logic Level - High | Max Propagation Delay @ V, Max CL | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
NLU1G08CMUTCGIC GATE AND 1CH 2-INP 6UDFN |
3,771 | 0.09 |
|
- |
MiniGate™ | 6-UFDFN | Tape & Reel (TR) | Active | AND Gate | 1 | 2 | - | 1.65V ~ 5.5V | 1 µA | 8mA, 8mA | - | - | 7.9ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-UDFN (1x1) |
|
NLX1G11BMX1TCGIC GATE AND 1CH 3-INP 6ULLGA |
1,319 | 0.09 |
|
Datasheet |
- | 6-XFLGA | Tape & Reel (TR) | Obsolete | AND Gate | 1 | 3 | - | 1.65V ~ 5.5V | 1 µA | 32mA, 32mA | - | - | 7ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-ULLGA (1.2x1) |
|
NC7ST32L6XIC GATE OR 1CH 2-INP 6MICROPAK |
101,376 | 0.00 |
|
Datasheet |
7ST | 6-UFDFN | Bulk | Active | OR Gate | 1 | 2 | - | 4.5V ~ 5.5V | 1 µA | 2mA, 2mA | 0.8V | 2V | 26ns @ 5.5V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 6-MicroPak |
|
|
NLX2G14BMX1TCGIC INVERT SCHMITT 2CH 2IN 6ULLGA |
2,282 | 0.09 |
|
- |
MiniGate™ | 6-XFLGA | Tape & Reel (TR) | Obsolete | Inverter | 2 | 2 | Schmitt Trigger | 1.65V ~ 5.5V | 1 µA | 32mA, 32mA | 0.2V ~ 1.2V | 1.4V ~ 3.6V | 4.9ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-ULLGA (1.2x1) |
|
NLU1GT04AMUTCGIC INVERTER 1CH 1-INP 6UDFN |
2,455 | 0.09 |
|
Datasheet |
MiniGate™ | 6-UFDFN | Tape & Reel (TR) | Obsolete | Inverter | 1 | 1 | - | 1.65V ~ 5.5V | 1 µA | 8mA, 8mA | 0.3V ~ 0.8V | 1.2V ~ 2V | 7.7ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-UDFN (1.45x1) |
|
MC74AC32DR2IC GATE OR 4CH 2-INP 14-SOIC |
82,475 | 0.09 |
|
Datasheet |
74AC | 14-SOIC (0.154", 3.90mm Width) | Bulk | Active | OR Gate | 4 | 2 | - | 2V ~ 6V | 4 µA | 24mA, 24mA | 0.9V ~ 1.65V | 2.1V ~ 3.85V | 7.5ns @ 5V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 14-SOIC |
|
SC7S08FERIC GATE AND |
81,000 | 0.09 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
NLU1GT32CMX1TCGIC GATE OR 1CH 2-INP 6ULLGA |
72,000 | 0.09 |
|
Datasheet |
MiniGate™ | 6-XFLGA | Bulk | Obsolete | OR Gate | 1 | 2 | - | 1.65V ~ 5.5V | 2 µA | 8mA, 8mA | 0.3V ~ 0.8V | 1.2V ~ 2V | 7.5ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-ULLGA (1x1) |
|
|
NLU1G00CMX1TCGIC GATE NAND 1CH 2-INP 6ULLGA |
72,000 | 0.09 |
|
Datasheet |
MiniGate™ | 6-XFLGA | Bulk | Obsolete | NAND Gate | 1 | 2 | - | 1.65V ~ 5.5V | 1 µA | 8mA, 8mA | - | - | 7.9ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-ULLGA (1x1) |
|
|
NLU1GT04CMX1TCGIC INVERTER 1CH 1-INP 6ULLGA |
69,000 | 0.09 |
|
Datasheet |
MiniGate™ | 6-XFLGA | Bulk | Obsolete | Inverter | 1 | 1 | - | 1.65V ~ 5.5V | 1 µA | 8mA, 8mA | 0.3V ~ 0.8V | 1.2V ~ 2V | 7.7ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-ULLGA (1x1) |
|
|
NLU1GT86CMX1TCGIC GATE XOR 1CH 2-INP 6ULLGA |
4,428 | 0.09 |
|
Datasheet |
MiniGate™ | 6-XFLGA | Tape & Reel (TR) | Obsolete | XOR (Exclusive OR) | 1 | 2 | - | 1.65V ~ 5.5V | 1 µA | 8mA, 8mA | 0.53V ~ 0.8V | 1.4V ~ 2V | 8.8ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-ULLGA (1x1) |
|
SN74LVC1G00DBV3IC GEN PURP |
68,900 | 0.09 |
|
Datasheet |
74LVC | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
MC74HC02ADR2IC GATE NOR 4CH 2-INP 14-SOIC |
68,585 | 0.09 |
|
Datasheet |
74HC | 14-SOIC (0.154", 3.90mm Width) | Bulk | Active | NOR Gate | 4 | 2 | - | 2V ~ 6V | 1 µA | 5.2mA, 5.2mA | 0.5V ~ 1.8V | 1.5V ~ 4.2V | 13ns @ 6V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 14-SOIC |
|
SN74LVC1G08DPKRIC GATE AND SNGL 2-INP |
67,000 | 0.09 |
|
Datasheet |
74LVC | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
NLX1G10BMX1TCGIC GATE NAND 1CH 3-INP 6ULLGA |
66,000 | 0.09 |
|
Datasheet |
- | 6-XFLGA | Bulk | Obsolete | NAND Gate | 1 | 3 | - | 1.65V ~ 5.5V | 1 µA | 32mA, 32mA | - | - | 7ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-ULLGA (1.2x1) |
|
|
NLU1G14CMX1TCGIC INVERT SCHMITT 1CH 1IN 6ULLGA |
65,985 | 0.09 |
|
Datasheet |
MiniGate™ | 6-XFLGA | Bulk | Obsolete | Inverter | 1 | 1 | Schmitt Trigger | 1.65V ~ 5.5V | 1 µA | 8mA, 8mA | 0.9V ~ 1.65V | 2.2V ~ 3.85V | 10.6ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-ULLGA (1x1) |
|
|
NC7WZ32L8X-L22185IC GATE OR 2CH 2-INP 8UQFN |
1,777 | 0.00 |
|
Datasheet |
7WZ | 8-UFQFN | Tape & Reel (TR) | Obsolete | OR Gate | 2 | 2 | - | 1.65V ~ 5.5V | 1 µA | 32mA, 32mA | - | - | 3.7ns @ 5V, 50pF | -40°C ~ 85°C | - | - | Surface Mount | 8-UQFN (1.6x1.6) |
|
|
SC7S08FELIC GATE AND |
60,000 | 0.09 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
NLU1G86CMX1TCGIC GATE XOR 1CH 2-INP 6ULLGA |
2,603 | 0.09 |
|
Datasheet |
MiniGate™ | 6-XFLGA | Tape & Reel (TR) | Obsolete | XOR (Exclusive OR) | 1 | 2 | - | 1.65V ~ 5.5V | 1 µA | 8mA, 8mA | - | - | 8.8ns @ 5V, 50pF | -55°C ~ 125°C | - | - | Surface Mount | 6-ULLGA (1x1) |
|
SN74LVC1G02DCK3IC GEN PURP |
52,587 | 0.09 |
|
Datasheet |
74LVC | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
