PTC Resettable Fuses
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Voltage - Max | Current - Hold (Ih) (Max) | Current - Trip (It) | Current - Max | Time to Trip | Resistance - Initial (Ri) (Min) | Resistance - Post Trip (R1) (Max) | Resistance - 25°C (Typ) | Operating Temperature | Grade | Qualification | Ratings | Mounting Type | Size / Dimension | Height - Seated (Max) | Thickness (Max) | Lead Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PTSLR18126V450PTC RESET FUSE 6V 4.5A 1812 |
7,192 | 0.59 |
|
Datasheet |
1812 (4532 Metric), Concave | PTSLR1812 | Tape & Reel (TR) | Active | Polymeric | 6V | 4.5 A | 9 A | 50 A | 2 s | 1 mOhms | 14 mOhms | - | -40°C ~ 85°C | - | - | - | Surface Mount | 0.179" L x 0.128" W (4.55mm x 3.24mm) | - | 0.047" (1.20mm) | - |
|
YPCL0120NPTC RESET FUSE 265V 35MA RADIAL |
8,017 | 0.00 |
|
Datasheet |
Radial, Disc | YP | Bulk | Obsolete | Ceramic | 265V | 35 mA | 80 mA | 400 mA | - | - | - | 120 Ohms | 0°C ~ 60°C | - | - | - | Through Hole | 0.256" Dia x 0.197" T (6.50mm x 5.00mm) | 0.315" (8.00mm) | - | 0.200" (5.08mm) |
|
|
YPCJ0070TPTC RESET FUSE 265V 30MA RADIAL |
8,507 | 0.00 |
|
Datasheet |
Radial, Disc | YP | Tape & Reel (TR) | Obsolete | Ceramic | 265V | 30 mA | 70 mA | 400 mA | - | - | - | 70 Ohms | 0°C ~ 60°C | - | - | - | Through Hole | 0.256" Dia x 0.197" T (6.50mm x 5.00mm) | 0.315" (8.00mm) | - | 0.200" (5.08mm) |
|
PTR060V0375-TRPTC RESET FUSE 60V 3.75A RADIAL |
8,485 | 0.59 |
|
Datasheet |
Radial, Disc | PTR060V | Tape & Reel (TR) | Obsolete | Polymeric | 60V | 3.75 A | 7.5 A | 40 A | 24 s | 30 mOhms | 80 mOhms | - | -40°C ~ 85°C | - | - | - | Through Hole | 1.118" Dia x 0.118" T (28.40mm x 3.00mm) | 1.319" (33.50mm) | - | 0.394" (10.00mm) |
|
|
PTR060V0375-TR1PTC RESET FUSE 60V 3.75A RADIAL |
6,907 | 0.59 |
|
Datasheet |
Radial, Disc | PTR060V | Tape & Reel (TR) | Obsolete | Polymeric | 60V | 3.75 A | 7.5 A | 40 A | 24 s | 30 mOhms | 80 mOhms | - | -40°C ~ 85°C | - | - | - | Through Hole | 1.118" Dia x 0.118" T (28.40mm x 3.00mm) | 1.319" (33.50mm) | - | 0.394" (10.00mm) |
|
MF-RHT1100-AP-14PTC 11.0A 16V RADIAL LEADED HI-T |
7,079 | 0.67 |
|
Datasheet |
Radial, Disc | Multifuse®, MF-R | Tape & Box (TB) | Active | Polymeric | 16V | 11 A | 20 A | 100 A | 11 s | 5.5 mOhms | 13 mOhms | - | -40°C ~ 125°C | Automotive | AEC-Q200 | - | Through Hole | 0.827" L x 0.118" W (21.00mm x 3.00mm) | 1.028" (26.10mm) | - | 0.402" (10.20mm) |
|
|
MF-RHT1100-2-14PTC 11.0A 16V RADIAL LEADED HI-T |
4,674 | 0.67 |
|
Datasheet |
Radial, Disc | Multifuse®, MF-R | Tape & Reel (TR) | Active | Polymeric | 16V | 11 A | 20 A | 100 A | 11 s | 5.5 mOhms | 13 mOhms | - | -40°C ~ 125°C | Automotive | AEC-Q200 | - | Through Hole | 0.827" L x 0.118" W (21.00mm x 3.00mm) | 1.028" (26.10mm) | - | 0.402" (10.20mm) |
|
MF-USMD075-2PTC RESET FUSE 6V 750MA 1210 |
8,133 | 0.00 |
|
Datasheet |
1210 (3225 Metric) | Multifuse®, MF-USMD | Tape & Reel (TR) | Obsolete | Polymeric | 6V | 750 mA | 1.5 A | 40 A | 100 ms | 70 mOhms | 450 mOhms | - | -40°C ~ 85°C | - | - | - | Surface Mount | 0.127" L x 0.102" W (3.22mm x 2.58mm) | - | 0.024" (0.62mm) | - |
|
2016L300/16DRPTC RESET FUSE 16V 3A 2016 |
8,646 | 0.00 |
|
Datasheet |
2016 (5041 Metric), Concave | POLY-FUSE®, 2016L | Tape & Reel (TR) | Obsolete | Polymeric | 16V | 3 A | 5 A | 40 A | 10 s | 15 mOhms | 48 mOhms | - | -40°C ~ 85°C | - | - | - | Surface Mount | 0.200" L x 0.160" W (5.08mm x 4.07mm) | - | 0.061" (1.55mm) | - |
|
SMDC050F-2PTC RESET FUSE 60V 500MA 2920 |
8,830 | 0.27 |
|
Datasheet |
2920 (7351 Metric), Concave | SMDC | Tape & Reel (TR) | Active | Polymeric | 60V | 500 mA | 1 A | 10 A | 4 s | 150 mOhms | 1.2 Ohms | - | - | - | - | - | Surface Mount | 0.295" L x 0.201" W (7.50mm x 5.10mm) | - | 0.035" (0.90mm) | - |
|
MF-USML550/6-2PTC RESET FUSE 6V 5.5A 1210 |
8,211 | 0.80 |
|
Datasheet |
1210 (3225 Metric), Concave | Multifuse®, MF-USML/X | Tape & Reel (TR) | Active | Polymeric | 6V | 5.5 A | 11 A | 50 A | 2 s | 1 mOhms | 10 mOhms | - | -40°C ~ 85°C | - | - | - | Surface Mount | 0.127" L x 0.101" W (3.22mm x 2.58mm) | - | 0.047" (1.20mm) | - |
|
PTGL07AR650H8B52B0PTC RESET FUSE 265V 84MA RADIAL |
4,568 | 0.00 |
|
Datasheet |
Radial, Disc | POSISTOR®, PTGL | Bulk | Obsolete | Ceramic | 265V | 84 mA | 162 mA | 1 A | - | - | - | 65 Ohms | -10°C ~ 60°C | - | - | - | Through Hole | 0.315" Dia x 0.236" T (8.00mm x 6.00mm) | 0.551" (14.00mm) | - | 0.197" (5.00mm) |
|
B59950C0120A051PTC RESET FUSE 80V 320MA RADIAL |
4,206 | 0.70 |
|
Datasheet |
Radial, Disc | B59950 | Tape & Reel (TR) | Active | Ceramic | 80V | 320 mA | 640 mA | 5.5 A | - | - | - | 3.7 Ohms | -40°C ~ 85°C | - | - | - | Through Hole | 0.532" Dia x 0.138" T (13.50mm x 3.50mm) | 0.669" (17.00mm) | - | 0.197" (5.00mm) |
|
PTGL09AS120K6B51B0PTC RESET FUSE 140V 244MA RADIAL |
5,329 | 0.00 |
|
Datasheet |
Radial, Disc | POSISTOR®, PTGL | Bulk | Obsolete | Ceramic | 140V | 244 mA | 324 mA | 2 A | - | - | - | 12 Ohms | -30°C ~ 85°C | - | - | - | Through Hole | 0.366" Dia x 0.177" T (9.30mm x 4.50mm) | 0.563" (14.30mm) | - | 0.197" (5.00mm) |
|
|
BK250-1500-SZPTC RESET FUSE 250V 1.5A RAD |
4,026 | 0.00 |
|
Datasheet |
Radial, Disc | BK250 | Bulk | Active | Polymeric | 250V | 1.5 A | 3 A | 10 A | 23 s | 200 mOhms | 600 mOhms | - | -40°C ~ 85°C | - | - | - | Through Hole | 0.827" L x 0.181" W (21.00mm x 4.60mm) | 1.083" (27.50mm) | - | 0.402" (10.20mm) |
|
PTR016V1200-TR1PTC RESET FUSE 16V 12A RADIAL |
2,142 | 0.57 |
|
Datasheet |
Radial, Disc | PTR016V | Tape & Reel (TR) | Active | Polymeric | 16V | 12 A | 20.4 A | 100 A | 7.5 s | 3 mOhms | 9 mOhms | - | -40°C ~ 85°C | - | - | - | Through Hole | 0.689" L x 0.122" W (17.50mm x 3.10mm) | 1.220" (31.00mm) | - | 0.394" (10.00mm) |
|
|
MINISMDC035-2PTC RESET FUSE 6V 350MA 1210 |
4,634 | 0.00 |
|
- |
1210 (3225 Metric), Concave | PolySwitch®, miniSMD | Tape & Reel (TR) | Obsolete | - | 6V | 350 mA | 700 mA | 40 A | 0.1 s | 320 mOhms | 1.3 Ohms | - | -40°C ~ 85°C | - | - | - | Surface Mount | 0.127" L x 0.102" W (3.22mm x 2.58mm) | - | 0.024" (0.62mm) | - |
|
YQD100N0150PTC RESET FUSE 265V 38MA RADIAL |
6,745 | 0.00 |
|
Datasheet |
Radial, Disc | YQ | Bulk | Active | Ceramic | 265V | 38 mA | 80 mA | 300 mA | - | - | - | 150 Ohms | 0°C ~ 60°C | - | - | - | Through Hole | 0.256" Dia x 0.197" T (6.50mm x 5.00mm) | - | - | 0.201" (5.10mm) |
|
|
YQS8119PTC RESET FUSE 265V 15MA RADIAL |
9,824 | 0.63 |
|
Datasheet |
Radial, Disc | YP | Bulk | Active | Ceramic | 265V | 15 mA | 45 mA | 200 mA | - | - | - | 150 Ohms | 0°C ~ 60°C | - | - | - | Through Hole | 0.177" Dia x 0.197" T (4.50mm x 5.00mm) | 0.354" (9.00mm) | - | 0.236" (6.00mm) |
|
B59870C0080A051PTC RESET FUSE 265V 60MA RADIAL |
2,884 | 0.80 |
|
Datasheet |
Radial, Disc | - | Tape & Reel (TR) | Active | Ceramic | 265V | 60 mA | 130 mA | 1 A | - | - | - | 25 Ohms | 0°C ~ 60°C | - | - | - | Through Hole | 0.354" Dia x 0.197" T (9.00mm x 5.00mm) | 0.492" (12.50mm) | - | 0.197" (5.00mm) |
