Pulse Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TG42-1505N5LFISO MOD T1 1C:1.41C X-TEMP 16P S |
3,724 | 0.00 |
|
Datasheet |
- | Tube | Active | T1/E1 (Dual) | 1.5mH | - | 1CT:1.41CT Transmitter, 1CT:1.41CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
TG27-1505N5LFISO MOD T1 1C:2C 1C:1.36C X-TEMP |
1,125 | 0.00 |
|
Datasheet |
- | Tube | Active | T1/E1 (Dual) | 1.5mH | - | 1CT:2CT Transmitter, 1CT:1.36CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
TG81-1006NLFISO MOD 10BASE-T 1C:1C 16P SMD |
1,452 | 0.00 |
|
Datasheet |
- | Tube | Active | LAN 10 Base-T | 100µH | - | 1CT:1CT Transmitter, 1CT:1CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG64-1505N5LFISO MOD T1 1:1:1.26 1C:2C X-TEMP |
2,884 | 0.00 |
|
Datasheet |
- | Tube | Active | T1/E1 (Dual) | 1.5mH | - | 1:1:1.26 Transmitter, 1CT:2CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.250" (6.35mm) | -45°C ~ 85°C | - | - |
|
|
TG26-1505N5LFISO MOD T1 DUAL 1C:2C X-TEMP 16P |
1,068 | 0.00 |
|
Datasheet |
- | Tube | Active | T1/E1 (Dual) | 1.5mH | - | 1CT:2CT Transmitter, 1CT:2CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
TG63-1505N5LFISO MOD T1 1C:1.15C 1C:2C X-TEMP |
3,687 | 0.00 |
|
Datasheet |
- | Tube | Active | T1/E1 (Dual) | 1.5mH | - | 1:1.15CT Transmitter, 1CT:2CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
NS0015 LFMDL SMD 10/100 SINGLE PORT N/A |
2,232 | 1.73 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10/100 Base-T | 350µH | - | 1:1CT Transmitter, 1:1CT Receiver | Surface Mount | 0.500" L x 0.276" W (12.70mm x 7.00mm) | 0.079" (2.00mm) | 0°C ~ 70°C | - | - |
|
|
TD42-2006QRLISO MOD 10BASE-T 1C:1.41C 16P TH |
3,101 | 0.00 |
|
- |
- | Tube | Not For New Designs | LAN 10 Base-T | 200µH | - | 1CT:1CT Transmitter, 1CT:1.41CT Receiver | Through Hole | 0.810" L x 0.300" W (20.57mm x 7.62mm) | 0.210" (5.33mm) | -40°C ~ 85°C | - | - |
|
750510165XFRM VX180-IFE6 POTS DAUGHTERBRD |
3,810 | 2.13 |
|
Datasheet |
MID-DSLIKN | Tape & Reel (TR) | Active | VDSL | 1.2mH | - | 3:1 | Surface Mount | 0.385" L x 0.360" W (9.78mm x 9.14mm) | 0.415" (10.54mm) | -40°C ~ 85°C | - | - |
|
|
S558-5999-T9-FMODULE XFRMR |
4,745 | 0.00 |
|
- |
- | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - |
|
|
G1PM109RNS2 LFMDL 1G DIP SINGLE PORT N/A |
3,297 | 1.74 |
|
Datasheet |
- | Tube | Active | LAN 1000 Base-T | 350µH | - | 1:1CT Transmitter, 1:1CT Receiver | Through Hole | 0.616" L x 0.433" W (15.65mm x 11.00mm) | 0.441" (11.20mm) | 0°C ~ 70°C | - | - |
|
|
TG08-1505N5LFTRISO MOD T1 1C:2C X-TEMP 16P SMD |
1,250 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | T1/E1 (Dual) | 1.5mH | - | 1CT:2CT Transmitter, 1CT:2CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
PA2006NLTPULSE XFMR 1:1 864UH |
3,359 | 1.73 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | 864µH | 26VµS | 1:1 | Surface Mount | 0.340" L x 0.460" W (8.64mm x 11.68mm) | 0.160" (4.06mm) | -40°C ~ 130°C | - | - |
|
|
MGBBT-00258-PCEP7 SMD 8PIN 1SEC,ROHS MGBBT-00 |
4,047 | 1.75 |
|
- |
* | Tape & Reel (TR) | Obsolete | - | - | - | - | - | - | - | - | - | - |
|
|
TX1314NLTTRANSFORMER 1:1/1.26 1.2MH SMD |
1,159 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Obsolete | T1/E1 (Single) | 1.2mH | - | 1:1/1.26 | Surface Mount | 0.300" L x 0.276" W (7.62mm x 7.00mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
TG01-1506NLFTRISO MOD AUI 3CH 16P SMD T/R |
4,654 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | 150µH | - | 1:1 | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG110-S055N2LFISO MOD 10/100 16P SMD |
2,792 | 0.00 |
|
Datasheet |
- | Tube | Active | LAN 10/100 Base-TX | - | - | 1CT:1CT Transmitter, 1CT:1CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG110-S050N2LFISO MOD 10/100 16P SMD |
3,000 | 0.00 |
|
Datasheet |
- | Tube | Active | LAN 10/100 Base-T | - | - | 1CT:1CT Transmitter, 1CT:1CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG07-0206NSRLTRISO MOD T3 1:2C 6P SMD T/R |
1,624 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | T3/E3 (Single) | 19µH | - | 1:2CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
TG04-0406NSRLTRISO MOD T3 1CH 1C:1C X-TEMP 6P S |
2,122 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | T3/E3 (Single) | 40µH | - | 1CT:1CT | Surface Mount | 0.320" L x 0.280" W (8.13mm x 7.11mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
