Current Sense Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Frequency Range | Type | Current Rating (Amps) | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Current Ratio | DC Resistance (DCR) | Ratings | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CSE5-100401CURR SENSE XFMR 1:40 10A SMD |
344 | 3.48 |
|
Datasheet |
- | Tape & Reel (TR) | Active | 250kHz Min | Invasive | 10 A | 320 µH | - | 1:40 | - | 1.14Ohm Secondary | - | Surface Mount | 0.272" L x 0.303" W (6.90mm x 7.70mm) | 0.210" (5.33mm) | Gull Wing |
|
|
CSE5-100601CURR SENSE XFMR 1:60 10A SMD |
337 | 3.48 |
|
Datasheet |
- | Tape & Reel (TR) | Active | 250kHz Min | Invasive | 10 A | 720 µH | - | 1:60 | - | 1.75Ohm Secondary | - | Surface Mount | 0.272" L x 0.303" W (6.90mm x 7.70mm) | 0.210" (5.33mm) | Gull Wing |
|
|
CSE5-100501CURR SENSE XFMR 1:50 10A SMD |
209 | 3.48 |
|
Datasheet |
- | Tape & Reel (TR) | Active | 250kHz Min | Invasive | 10 A | 500 µH | - | 1:50 | - | 1.5Ohm Secondary | - | Surface Mount | 0.272" L x 0.303" W (6.90mm x 7.70mm) | 0.210" (5.33mm) | Gull Wing |
|
PH9494.100NLTCURR SENSE XFMR 100:1 30A SMD |
1,624 | 2.63 |
|
Datasheet |
PH9494.XXXNLT | Tape & Reel (TR) | Active | 20kHz | Invasive | 30 A | 2.5 mH | - | 100:1 | - | 0.35mOhm Primary, 3Ohm Secondary | - | Surface Mount | 0.504" L x 0.382" W (12.80mm x 9.70mm) | 0.283" (7.20mm) | Gull Wing |
|
|
PH9494.150NLTCURR SENSE XFMR 150:1 30A SMD |
333 | 2.63 |
|
Datasheet |
PH9494.XXXNLT | Tape & Reel (TR) | Active | 20kHz | Invasive | 30 A | 5.63 mH | - | 150:1 | - | 0.35mOhm Primary, 5.7Ohm Secondary | - | Surface Mount | 0.504" L x 0.382" W (12.80mm x 9.70mm) | 0.283" (7.20mm) | Gull Wing |
|
|
PH9494.050NLTCURR SENSE XFMR 50:1 30A SMD |
523 | 2.63 |
|
Datasheet |
PH9494.XXXNLT | Tape & Reel (TR) | Active | 20kHz | Invasive | 30 A | 630 µH | - | 50:1 | - | 0.35mOhm Primary, 600mOhm Secondary | - | Surface Mount | 0.504" L x 0.382" W (12.80mm x 9.70mm) | 0.283" (7.20mm) | Gull Wing |
|
ECSTA1V0805-1125-RCURR SENSE XFMR 125:1 10A SM |
2,214 | 3.02 |
|
Datasheet |
ECSTA | Tape & Reel (TR) | Active | 50kHz ~ 1MHz | Invasive | 10 A | 3 mH | - | 125:1 | - | 700mOhm Primary, 11.5Ohm Secondary Max | AEC-Q200 | Surface Mount | 0.330" L x 0.315" W (8.38mm x 8.00mm) | 0.217" (5.50mm) | Gull Wing |
|
CSE187L-BCURR SENSE XFMR 1:500 TH |
2,311 | 2.02 |
|
- |
CSE187 | - | Active | - | - | - | - | - | 1:500 | - | 250mOhm Max | - | Through Hole | 0.875" L x 0.875" W (22.23mm x 22.23mm) | 0.720" (18.29mm) | PC Pin |
|
PCS020-EE05730SCURRENT SENSE TRANSF 20A 730UH |
981 | 5.37 |
|
Datasheet |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 20 A | 0.73 mH | 32.4VµS | 1:60 | 60:1 | 7mOhm Primary, 1.98Ohm Secondary Max | - | Surface Mount | 0.245" L x 0.235" W (6.22mm x 5.97mm) | 0.209" (5.31mm) | Gull Wing |
|
|
PCS020-EE0502KSCURRENT SENSE TRANSF 20A 2000UH |
813 | 5.37 |
|
Datasheet |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 20 A | 2 mH | 54VµS | 1:100 | 100:1 | 7mOhm Primary, 5.5Ohm Secondary Max | - | Surface Mount | 0.245" L x 0.235" W (6.22mm x 5.97mm) | 0.209" (5.31mm) | Gull Wing |
|
|
PCS020-EE05081SCURRENT SENSE TRANSF 20A 81UH |
983 | 5.37 |
|
Datasheet |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 20 A | 81 mH | 10.8VµS | 1:20 | 20:1 | 7mOhm Primary, 400mOhm Secondary Max | - | Surface Mount | 0.245" L x 0.235" W (6.22mm x 5.97mm) | 0.209" (5.31mm) | Gull Wing |
|
|
PCS040-EF1303KSCURRENT SENSE TRANSF 40A 3060UH |
290 | 5.13 |
|
Datasheet |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 3.06 mH | 152.4VµS | 1:60 | 60:1 | 1mOhm Primary, 850mOhm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
|
PCS040-EF1301KSCURRENT SENSE TRANSF 40A 1360UH |
290 | 5.13 |
|
Datasheet |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 1.36 mH | 101.6VµS | 1:40 | 40:1 | 1mOhm Primary, 560mOhm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
|
PCS040-EF1334KSCURRENT SENSE TRANSF 40A 34000UH |
256 | 5.13 |
|
Datasheet |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 34 mH | 508VµS | 1:200 | 200:1 | 1mOhm Primary, 4.06Ohm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
|
PCS020-EE0503KSCURRENT SENSE TRANSF 20A 3000UH |
980 | 5.37 |
|
Datasheet |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 20 A | 3 H | 67.5VµS | 1:125 | 125:1 | 7mOhm Primary, 7Ohm Secondary Max | - | Surface Mount | 0.245" L x 0.235" W (6.22mm x 5.97mm) | 0.209" (5.31mm) | Gull Wing |
|
|
PCS040-EF1319KSCURRENT SENSE TRANSF 40A 19200UH |
299 | 5.13 |
|
Datasheet |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 19.2 mH | 381VµS | 1:150 | 150:1 | 1mOhm Primary, 2.25Ohm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
|
PCS040-EF1305KSCURRENT SENSE TRANSF 40A 5440UH |
272 | 5.13 |
|
Datasheet |
PCS | Tape & Reel (TR) | Active | 1MHz | Invasive | 40 A | 5.44 mH | 203.2VµS | 1:80 | 80:1 | 1mOhm Primary, 1.15Ohm Secondary Max | - | Surface Mount | - | 0.413" (10.50mm) | Gull Wing |
|
T60404E4622X503CURR SENSE XFMR 2000:1 20A TH |
3,353 | 0.00 |
|
Datasheet |
- | Box | Obsolete | 50Hz ~ 60Hz | Non-Invasive (Solid Core) | 20 A | 238 H | - | 1:2000 | 2000:1 | 114Ohm | - | Through Hole | 0.965" L x 0.484" W (24.50mm x 12.30mm) | 0.994" (25.25mm) | PC Pin |
|
|
CR8349-1500-NCURR SENSE XFMR T/H |
167 | 19.20 |
|
- |
CR8300 | Bulk | Active | 20Hz ~ 1kHz | Non-Invasive (Solid Core) | - | - | - | - | - | - | - | Through Hole | 1.024" L x 0.670" W (26.00mm x 17.00mm) | 1.102" (28.00mm) | PC Pin |
|
ACTL-0750-150 OPT C0.6CURR SENS XFMR 100:1 150A INLINE |
4,738 | 82.14 |
|
- |
Accu-CT® | Bag | Active | 50/60Hz | Non-Invasive (Split Core) | 150 A | - | - | 100:1 | - | - | - | Free Hanging (In-Line) | 2.378" L x 0.902" W (60.40mm x 22.90mm) | 2.402" (61.00mm) | Wire Leads |
