PTC Resettable Fuses
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Type | Voltage - Max | Current - Hold (Ih) (Max) | Current - Trip (It) | Current - Max | Time to Trip | Resistance - Initial (Ri) (Min) | Resistance - Post Trip (R1) (Max) | Resistance - 25°C (Typ) | Operating Temperature | Grade | Qualification | Ratings | Mounting Type | Size / Dimension | Height - Seated (Max) | Thickness (Max) | Lead Spacing |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
2322 661 93124PTC RESET FUSE 350V 70MA RADIAL |
4,856 | 0.00 |
|
Datasheet |
Radial, Disc | - | Bulk | Obsolete | Ceramic | 350V | 70 mA | 270 mA | 1 A | 4 s | - | - | 10 Ohms | - | - | - | - | Through Hole | 0.335" Dia x 0.197" T (8.50mm x 5.00mm) | 0.453" (11.50mm) | - | 0.197" (5.00mm) |
|
PFRY.135PTC RESET FUSE 72V 1.35A RADIAL |
8,347 | 0.58 |
|
Datasheet |
Radial, Disc | PFRY | Bulk | Active | Polymeric | 72V | 1.35 A | 2.7 A | 40 A | 9.6 s | 120 mOhms | 300 mOhms | - | -40°C ~ 85°C | - | - | - | Through Hole | 0.483" L x 0.118" W (12.26mm x 3.00mm) | 0.720" (18.30mm) | - | 0.201" (5.10mm) |
|
PTR016V0500-TR1PTC RESET FUSE 16V 5A RADIAL |
9,168 | 0.39 |
|
Datasheet |
Radial, Disc | PTR016V | Tape & Reel (TR) | Active | Polymeric | 16V | 5 A | 8.5 A | 100 A | 2 s | 10 mOhms | 34 mOhms | - | -40°C ~ 85°C | - | - | - | Through Hole | 0.409" L x 0.122" W (10.40mm x 3.10mm) | 0.630" (16.00mm) | - | 0.197" (5.00mm) |
|
PTGL04AS560K6B51A0PTC RESET FUSE 140V 94MA RADIAL |
2,799 | 0.00 |
|
Datasheet |
Radial, Disc | POSISTOR®, PTGL | Bulk | Obsolete | Ceramic | 140V | 94 mA | 125 mA | 500 mA | - | - | - | 56 Ohms | -30°C ~ 85°C | - | - | - | Through Hole | 0.177" Dia x 0.177" T (4.50mm x 4.50mm) | 0.374" (9.50mm) | - | 0.197" (5.00mm) |
|
|
E04213-000VTP170F |
8,492 | 0.00 |
|
- |
- | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
0ZRN0550FF2BPTC RESET FUSE 16V 5.5A RADIAL |
8,063 | 0.45 |
|
Datasheet |
Radial, Disc | 0ZRN | Tape & Reel (TR) | Active | Polymeric | 16V | 5.5 A | 10 A | 100 A | 6 s | 15 mOhms | 37 mOhms | - | -40°C ~ 125°C | Automotive | AEC-Q200 | - | Through Hole | 0.441" L x 0.118" W (11.20mm x 3.00mm) | 0.744" (18.90mm) | - | 0.201" (5.10mm) |
|
PTGL9SAS120K6B51A0PTC RESET FUSE 140V 244MA RADIAL |
4,840 | 0.00 |
|
Datasheet |
Radial, Disc | POSISTOR®, PTGL | Bulk | Obsolete | Ceramic | 140V | 244 mA | 324 mA | 2 A | - | - | - | 12 Ohms | -30°C ~ 125°C | - | - | - | Through Hole | 0.366" Dia x 0.177" T (9.30mm x 4.50mm) | 0.563" (14.30mm) | - | 0.197" (5.00mm) |
|
1206L110WRPTC RESET FUSE 8V 1.1A 1206 |
6,010 | 0.00 |
|
Datasheet |
1206 (3216 Metric), Concave | POLY-FUSE®, 1206L | Tape & Reel (TR) | Obsolete | Polymeric | 8V | 1.1 A | 2.2 A | 100 A | 100 ms | 40 mOhms | 180 mOhms | - | -40°C ~ 85°C | - | - | - | Surface Mount | 0.126" L x 0.065" W (3.20mm x 1.65mm) | - | 0.039" (1.00mm) | - |
|
|
1206L150PRPTC RESET FUSE 8V 1.5A 1206 |
5,530 | 0.00 |
|
Datasheet |
1206 (3216 Metric), Concave | POLY-FUSE®, 1206L | Tape & Reel (TR) | Obsolete | Polymeric | 8V | 1.5 A | 3 A | 100 A | 300 ms | 40 mOhms | 120 mOhms | - | -40°C ~ 85°C | - | - | - | Surface Mount | 0.126" L x 0.065" W (3.20mm x 1.65mm) | - | 0.055" (1.40mm) | - |
|
|
1206L100WRPTC RESET FUSE 6V 1A 1206 |
7,620 | 0.00 |
|
Datasheet |
1206 (3216 Metric), Concave | POLY-FUSE®, 1206L | Tape & Reel (TR) | Obsolete | Polymeric | 6V | 1 A | 1.8 A | 100 A | 300 ms | 55 mOhms | 210 mOhms | - | -40°C ~ 85°C | - | - | - | Surface Mount | 0.126" L x 0.065" W (3.20mm x 1.65mm) | - | 0.030" (0.75mm) | - |
|
PTCCL05H131FTEPTC RESET FUSE 145V 130MA RADIAL |
3,511 | 1.15 |
|
Datasheet |
Radial, Disc | PTCCL - 145V | Tape & Reel (TR) | Obsolete | Ceramic | 145V | 130 mA | 195 mA | 600 mA | - | - | - | 28 Ohms | 0°C ~ 70°C | - | - | - | Through Hole | 0.197" Dia x 0.197" T (5.00mm x 5.00mm) | 0.394" (10.00mm) | - | 0.197" (5.00mm) |
|
|
PTGL4SAS560K6B51B0PTC RESET FUSE 140V 94MA RADIAL |
8,694 | 0.00 |
|
Datasheet |
Radial, Disc | POSISTOR®, PTGL | Bulk | Obsolete | Ceramic | 140V | 94 mA | 125 mA | 500 mA | - | - | - | 56 Ohms | -30°C ~ 125°C | - | - | - | Through Hole | 0.177" Dia x 0.177" T (4.50mm x 4.50mm) | 0.374" (9.50mm) | - | 0.197" (5.00mm) |
|
|
SMD2920P300TF/15APTC RESET FUSE 15V 3A 2920 |
6,938 | 0.00 |
|
- |
2920 (7351 Metric), Concave | POLY-FUSE®, SMD2920 | Tape & Reel (TR) | Obsolete | Polymeric | 15V | 3 A | 6 A | 40 A | 20 s | 15 mOhms | 48 mOhms | - | -40°C ~ 85°C | - | - | - | Surface Mount | 0.290" L x 0.202" W (7.36mm x 5.12mm) | - | 0.039" (1.00mm) | - |
|
|
PTR016V0900-TRPTC RESET FUSE 16V 9A RADIAL |
6,609 | 0.39 |
|
Datasheet |
Radial, Disc | PTR016V | Tape & Reel (TR) | Active | Polymeric | 16V | 9 A | 15.3 A | 100 A | 5.5 s | 5 mOhms | 14 mOhms | - | -40°C ~ 85°C | - | - | - | Through Hole | 0.551" L x 0.122" W (14.00mm x 3.10mm) | 0.862" (21.90mm) | - | 0.197" (5.00mm) |
|
|
PFHT.136.2PFHT PTC FUSE SMT 1.36 A |
2,234 | 0.00 |
|
Datasheet |
2-SMD | PFHT | Bulk | Active | Polymeric | 16V | 1.36 A | 2.72 A | 100 A | 10 s | 104 mOhms | 300 mOhms | - | -40°C ~ 125°C | - | - | - | Surface Mount | 0.289" L x 0.214" W (7.36mm x 5.44mm) | 0.118" (3.00mm) | 0.118" (3.00mm) | - |
|
MF-RG900-APPTC RESET FUSE 16V 9A RADIAL |
5,340 | 0.48 |
|
Datasheet |
Radial, Disc | Multifuse®, MF-RG | Tape & Box (TB) | Active | Polymeric | 16V | 9 A | 15.3 A | 100 A | 12 s | 4 mOhms | 15 mOhms | - | -40°C ~ 85°C | - | - | - | Through Hole | 0.551" L x 0.118" W (14.00mm x 3.00mm) | 0.819" (20.80mm) | - | 0.201" (5.10mm) |
|
|
MF-R1100-2-14PTC RESETTABLE 1.1A 16V RADIAL L |
9,999 | 0.48 |
|
Datasheet |
Radial, Disc | Multifuse®, MF-R | Tape & Reel (TR) | Active | Polymeric | 16V | 11 A | 22 A | 100 A | 20 s | 3 mOhms | 14 mOhms | - | -40°C ~ 85°C | Automotive | AEC-Q200 | - | Through Hole | 0.953" L x 0.118" W (24.20mm x 3.00mm) | 1.295" (32.90mm) | - | 0.402" (10.20mm) |
|
|
MF-RG800-AP-14PTC RESETTABLE 8A 16V RADIAL LEA |
7,975 | 0.48 |
|
Datasheet |
Radial, Disc | Multifuse®, MF-RG | Tape & Box (TB) | Active | Polymeric | 16V | 8 A | 13.6 A | 100 A | 5 s | 5.6 mOhms | 17.5 mOhms | - | -40°C ~ 85°C | Automotive | AEC-Q200 | - | Through Hole | 0.500" L x 0.118" W (12.70mm x 3.00mm) | 0.823" (20.90mm) | - | 0.201" (5.10mm) |
|
|
MF-RG800-2-14PTC RESETTABLE 8A 16V RADIAL LEA |
7,881 | 0.48 |
|
Datasheet |
Radial, Disc | Multifuse®, MF-RG | Tape & Reel (TR) | Active | Polymeric | 16V | 8 A | 13.6 A | 100 A | 5 s | 5.6 mOhms | 17.5 mOhms | - | -40°C ~ 85°C | Automotive | AEC-Q200 | - | Through Hole | 0.500" L x 0.118" W (12.70mm x 3.00mm) | 0.823" (20.90mm) | - | 0.201" (5.10mm) |
|
|
MF-R1100-AP-14PTC RESETTABLE 1.1A 16V RADIAL L |
5,480 | 0.48 |
|
Datasheet |
Radial, Disc | Multifuse®, MF-R | Tape & Box (TB) | Active | Polymeric | 16V | 11 A | 22 A | 100 A | 20 s | 3 mOhms | 14 mOhms | - | -40°C ~ 85°C | Automotive | AEC-Q200 | - | Through Hole | 0.953" L x 0.118" W (24.20mm x 3.00mm) | 1.295" (32.90mm) | - | 0.402" (10.20mm) |
