Pulse Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TG111-E10NYNLFISO MOD 1G POE 0.35A X-TEMP 24P |
4,270 | 0.00 |
|
Datasheet |
- | Tube | Active | Isolation and Data Interface (Encapsulated) | 350µH | - | 1CT:1CT | Surface Mount | 0.560" L x 0.300" W (14.22mm x 7.62mm) | 0.340" (8.64mm) | -40°C ~ 85°C | - | - |
|
|
PE-65728TPULSE XFMR 1:1 100UH |
1,552 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Obsolete | LAN | 100µH | 1.8VµS | 1:1 | Surface Mount | 0.500" L x 0.285" W (12.70mm x 7.24mm) | 0.200" (5.08mm) | 0°C ~ 70°C | - | - |
|
|
PA1267NLPULSE XFMR 155.5UH |
1,952 | 2.26 |
|
Datasheet |
- | Tray | Active | - | 155.5µH | - | - | Surface Mount | 0.551" L x 0.516" W (14.00mm x 13.11mm) | 0.485" (12.32mm) | -40°C ~ 130°C | - | - |
|
|
TGAD-292NALFTRISO MOD DC 1C:5C 14VUS 6P SMD T/ |
4,102 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | 389µH | - | 1CT:5CT | Surface Mount | 0.380" L x 0.350" W (9.65mm x 8.89mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
PA1253NLTXFRMR 1.8V 1A 253UH POE EP10 SMD |
1,658 | 2.27 |
|
Datasheet |
EP10 | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | 253µH | - | 1:0.0625:0.271 | Surface Mount | 0.515" L x 0.600" W (13.08mm x 15.24mm) | 0.451" (11.45mm) | -40°C ~ 130°C | - | - |
|
|
S558-5500-05-FMODULE XFRMR |
2,982 | 0.00 |
|
- |
- | Bulk | Obsolete | - | - | - | - | - | - | - | - | - | - |
|
|
TG01-FC15NSLFTRISO MOD FBR 1CH 15UH 6P SMD T/R |
4,935 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | General Purpose | 15µH | - | - | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | - | - | - |
|
|
PA3342NLTPULSE XFMR 90UH |
2,732 | 2.29 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | 90µH | - | - | Surface Mount | 0.551" L x 0.516" W (14.00mm x 13.11mm) | 0.485" (12.32mm) | -40°C ~ 130°C | - | - |
|
|
PA1276NLXFMRPWR77.4UH10%EP13S NPB |
1,854 | 2.15 |
|
- |
PA1276NL | Tray | Active | Power over Ethernet (PoE) | 77.4µH | - | 1:0.682:0.682 | Surface Mount | 0.551" L x 0.516" W (14.00mm x 13.11mm) | 0.485" (12.32mm) | -40°C ~ 130°C | - | - |
|
|
LG2P109N LF(2.5MM)MDL 1G DIP DUAL PORT N/A |
4,075 | 2.29 |
|
- |
- | Tube | Active | LAN 1000 Base-T | 350µH | - | 1:1CT Transmitter, 1:1CT Receiver | Through Hole | 1.280" L x 0.335" W (32.50mm x 8.50mm) | 0.457" (11.60mm) | 0°C ~ 70°C | - | - |
|
|
PA1279NLTXFRMR 3.3V 3W 310UH POE EP7 SMD |
1,815 | 2.21 |
|
Datasheet |
EP7 | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | 310µH | - | 1:0.182:0.682 | Surface Mount | 0.420" L x 0.525" W (10.67mm x 13.34mm) | 0.365" (9.27mm) | -40°C ~ 125°C | - | - |
|
T60403D4721X007GATE DRIVE TRANSFORMER PTH 3:1:1 |
3,848 | 7.32 |
|
Datasheet |
- | Box | Active | Gate Drive | 8.5mH, 16mH | 250VµS | 3:1:1 | Through Hole | 0.701" L x 0.669" W (17.80mm x 17.00mm) | 0.531" (13.50mm) | -25°C ~ 85°C | - | - |
|
|
TG100-MOST15N5LFTRISO MOD MOST AEC 16P SMD T/R |
4,797 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | General Purpose | 250µH | - | 1CT:1.5CT Transmitter, 1CT:1CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | -40°C ~ 105°C | - | - |
|
|
T60403Y5046X0115046X011 |
3,443 | 0.00 |
|
Datasheet |
- | Box | Active | General Purpose | 4.6mH | 45VµS | - | Surface Mount | 0.669" L x 0.591" W (17.00mm x 15.00mm) | 0.358" (9.10mm) | -40°C ~ 85°C | - | - |
|
|
TG01-FC15NSLFISO MOD FBR 1CH 15UH 6P SMD |
1,825 | 0.00 |
|
Datasheet |
- | Tube | Active | General Purpose | 15µH | - | - | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.200" (5.08mm) | - | - | - |
|
ALAN-134-TPULSE XFMR 1CT:1CT 350UH |
1,793 | 2.45 |
|
Datasheet |
ALAN-134 | Tape & Reel (TR) | Active | LAN 10/100 Base-T | 350µH | - | 1CT:1CT | Surface Mount | 0.500" L x 0.272" W (12.70mm x 6.90mm) | 0.213" (5.40mm) | -40°C ~ 85°C | - | - |
|
PT61021ELINDUCTOR RADIAL |
2,493 | 2.91 |
|
Datasheet |
- | Bulk | Obsolete | - | - | - | - | - | 0.550" L x 0.480" W (13.96mm x 12.20mm) | 0.246" (6.25mm) | 0°C ~ 70°C | - | - |
|
|
TG63-1505NCRLISO MOD T1 1C:1.15C 1C:2C X-TEMP |
2,087 | 0.00 |
|
- |
- | Tube | Not For New Designs | T1/E1 (Dual) | - | - | 1:1.15CT Transmitter, 1CT:2CT Receiver | Surface Mount | 0.675" L x 0.455" W (17.15mm x 11.56mm) | 0.340" (8.64mm) | -40°C ~ 85°C | - | - |
|
|
TG110-S141N5LFISO MOD 10/100 1C:1.41C 16P SMD |
1,954 | 0.00 |
|
Datasheet |
- | Tube | Active | LAN 10/100 Base-TX | - | - | 1CT:1.41CT Transmitter, 1CT:1CT Receiver | Surface Mount | 0.500" L x 0.280" W (12.70mm x 7.11mm) | 0.250" (6.35mm) | 0°C ~ 70°C | - | - |
|
|
LG2P109N LFMDL 1G DIP DUAL PORT N/A |
2,511 | 2.32 |
|
- |
- | Tube | Active | LAN 1000 Base-T | 350µH | - | 1:1CT Transmitter, 1:1CT Receiver | Through Hole | 1.280" L x 0.335" W (32.50mm x 8.50mm) | 0.457" (11.60mm) | 0°C ~ 70°C | - | - |
