Pulse Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TG1G-S202NV6RLISO MOD 1G DUAL 48P SMD |
1,159 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | LAN 10/100 Base-T | - | - | - | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.280" (7.11mm) | 0°C ~ 70°C | - | - |
|
HU4108NLTMDL, SIN 2.5G, 1:1, SMT |
3,475 | 6.57 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | 150µH | - | - | Surface Mount | 0.600" L x 0.430" W (15.24mm x 10.93mm) | 0.340" (8.63mm) | 0°C ~ 70°C | - | - |
|
|
TG1G-S212NV6RLTRISO MOD 1G POE 0.35A DUAL 48P SM |
4,895 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10/100 Base-T | - | - | - | Surface Mount | 1.100" L x 0.625" W (27.94mm x 15.88mm) | 0.280" (7.11mm) | 0°C ~ 70°C | - | - |
|
|
PL1170TXFMR TOROID CS SLIC T&RCOM PBC |
1,051 | 6.65 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | - | - | 1:1:100 | Surface Mount | 0.495" L x 0.490" W (12.57mm x 12.45mm) | 0.280" (7.11mm) | - | - | - |
|
|
GH5610RS LFMDL 1G DIP QUAD PORTS POE+ 30W |
1,570 | 6.58 |
|
Datasheet |
- | Tube | Active | LAN 1000 Base-T | 350µH | - | 1:1CT Transmitter, 1:1CT Receiver | Through Hole | 1.142" L x 1.043" W (29.00mm x 26.50mm) | 0.512" (13.00mm) | 0°C ~ 70°C | - | - |
|
|
T60403F4615X0674615X067 |
3,698 | 0.00 |
|
Datasheet |
- | Box | Active | Gate Drive | 14.4mH | 500VµS | 1:1:1 | Through Hole | 0.906" L x 0.906" W (23.00mm x 23.00mm) | 0.650" (16.50mm) | -40°C ~ 70°C | - | - |
|
G513TRANSFORMER 1.2MH 1:1:1 PULSE |
4,780 | 6.60 |
|
Datasheet |
G5 | Tube | Active | Isolation and Data Interface (Encapsulated) | 1.2mH | 10VµS | 1:1:1 Ter | Through Hole | 0.350" L x 0.500" W (8.90mm x 12.70mm) | 0.250" (6.35mm) | 0°C ~ 70°C | - | - |
|
|
G507TRANSFORMER 0.50MH 2:1:1 PULSE |
3,805 | 6.60 |
|
Datasheet |
G5 | Tube | Active | Isolation and Data Interface (Encapsulated) | 500µH | 8.5VµS | 2:1:1 Ter | Through Hole | 0.350" L x 0.500" W (8.90mm x 12.70mm) | 0.250" (6.35mm) | 0°C ~ 70°C | - | - |
|
|
G512TRANSFORMER 2.0MH 2CT:1CT PULSE |
3,688 | 11.27 |
|
Datasheet |
G5 | Tube | Active | Isolation and Data Interface (Encapsulated) | 2mH | 16VµS | 2CT:1CT | Through Hole | 0.350" L x 0.500" W (8.90mm x 12.70mm) | 0.250" (6.35mm) | 0°C ~ 70°C | - | - |
|
|
G515TRANSFORMER 0.20MH 2CT:1CT PULSE |
2,027 | 11.27 |
|
Datasheet |
G5 | Tube | Active | Isolation and Data Interface (Encapsulated) | 200µH | 5VµS | 2CT:1CT | Through Hole | 0.350" L x 0.500" W (8.90mm x 12.70mm) | 0.250" (6.35mm) | 0°C ~ 70°C | - | - |
|
H7018FNLMODULE 10GBASE-T 1.5KVRMS SMD |
2,069 | 6.61 |
|
Datasheet |
- | Tube | Active | LAN 10G Base-T | 120µH | - | 1:1 | Surface Mount | 0.539" L x 0.591" W (13.70mm x 15.00mm) | 0.230" (5.85mm) | 0°C ~ 70°C | - | - |
|
2337822-2DISCRETE ETHERNET MAGNETICS SING |
3,265 | 6.26 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | - | - | - | Surface Mount | - | - | -40°C ~ 105°C | - | - |
|
|
HDX8004NLTMDL SIN HDBT 1:1 POEP SM TR |
1,120 | 6.62 |
|
Datasheet |
- | Tape & Reel (TR) | Active | HDBase-T | 120µH | - | 1:1 | Surface Mount | 0.540" L x 0.480" W (13.72mm x 12.20mm) | 0.225" (5.72mm) | -40°C ~ 85°C | - | - |
|
|
HD8006FNLTMDL SIN HDBT 1:1 POEPP SMT TR |
2,804 | 6.62 |
|
Datasheet |
- | Tape & Reel (TR) | Active | HDBase-T | 120µH | - | 1:1 | Surface Mount | 0.698" L x 0.625" W (17.73mm x 15.88mm) | 0.310" (7.87mm) | 0°C ~ 70°C | - | - |
|
|
TG1G-E220NWLFTRISO MOD 1G DUAL X-TEMP 50P SMD T |
1,660 | 0.00 |
|
- |
- | Tape & Reel (TR) | Active | Isolation and Data Interface (Encapsulated) | 350µH | - | - | Surface Mount | 1.100" L x 0.300" W (27.94mm x 7.62mm) | 0.340" (8.64mm) | -40°C ~ 85°C | - | - |
|
|
TG1G-S232NVRLTRISO MOD 1G DUAL 48P SMD T/R |
2,887 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10/100 Base-T | - | - | - | Surface Mount | 1.090" L x 0.600" W (27.69mm x 15.24mm) | 0.300" (7.62mm) | 0°C ~ 70°C | - | - |
|
|
H1036LNLTXFRMR MODULE 4PORT 1:1 10/100 |
4,458 | 0.00 |
|
- |
- | Tape & Reel (TR) | Obsolete | Isolation and Data Interface (Encapsulated) | - | - | 1:1 Transmitter, 1:1 Receiver | Surface Mount | 1.125" L x 0.485" W (28.58mm x 12.32mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
|
HU4108NLMODULE MAGNETIC SNGL 2.5GB SMT |
4,629 | 7.74 |
|
Datasheet |
- | Tube | Active | - | - | - | - | Surface Mount | 0.600" L x 0.300" W (15.24mm x 7.62mm) | 0.340" (8.63mm) | 0°C ~ 70°C | - | - |
|
|
TG10G-HPE6NZ5LFTRISO MOD 10G POE 0.6A X-TEMP 24P |
4,771 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10G Base-T | - | - | - | Surface Mount | 0.722" L x 0.485" W (18.33mm x 12.32mm) | 0.255" (6.48mm) | -40°C ~ 85°C | - | - |
|
|
TG1G-S202NV6RLTRISO MOD 1G DUAL 48P SMD T/R |
4,969 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Not For New Designs | LAN 10/100 Base-T | - | - | - | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.280" (7.11mm) | 0°C ~ 70°C | - | - |
