Pulse Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PE-68026NLT10BT FILTER MODULE WITH CMC |
1,741 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Obsolete | Isolation and Data Interface (Encapsulated) | - | - | 1:1 | Surface Mount | 0.920" L x 0.385" W (23.37mm x 9.78mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
|
TG110-RP16NV6RLISO MOD 10/100 QUAD POE 0.35A 48 |
3,047 | 0.00 |
|
- |
- | Tube | Not For New Designs | Power over Ethernet (PoE) | 350µH | - | 1CT:1CT | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.280" (7.11mm) | 0°C ~ 70°C | - | - |
|
|
TG1G-E201NV6LFISO MOD 1G DUAL X-TEMP 48P SMD |
1,012 | 0.00 |
|
Datasheet |
- | Tube | Active | LAN 10/100 Base-T | - | - | - | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.280" (7.11mm) | -40°C ~ 85°C | - | - |
|
|
TG110-RPE17NV6LFTRISO MOD 10/100 QUAD POE 0.35A |
2,920 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10/100 Base-TX | - | - | - | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.280" (7.11mm) | -40°C ~ 85°C | - | - |
|
|
GH5609S LFMDL 1G DIP QUAD PORTS POE+ 30W |
2,564 | 6.86 |
|
Datasheet |
- | Tube | Active | LAN 1000 Base-T | 350µH | - | 1:1CT Transmitter, 1:1CT Receiver | Through Hole | 1.142" L x 1.043" W (29.00mm x 26.50mm) | 0.512" (13.00mm) | 0°C ~ 70°C | - | - |
|
HM1331NLTMDL,SIN,100D,1:1,SMT |
3,062 | 6.92 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10/100 Base-T | 350µH | - | 1CT:1CT Transmitter, 1CT:1CT Receiver | Surface Mount | 0.500" L x 0.600" W (12.70mm x 15.24mm) | 0.300" (7.62mm) | -40°C ~ 85°C | - | - |
|
|
HDX8005NLTMDL SIN HDBT 1:1 POEP SM TR |
2,616 | 6.94 |
|
Datasheet |
- | Tape & Reel (TR) | Active | HDBase-T | 120µH | - | 1:1 | Surface Mount | 0.540" L x 0.480" W (13.72mm x 12.20mm) | 0.225" (5.72mm) | -40°C ~ 85°C | - | - |
|
|
T60403F4215X1804215X180 |
2,895 | 0.00 |
|
Datasheet |
- | Box | Active | Gate Drive | - | 170VµS | 1:1:1 | Through Hole | - | 0.571" (14.50mm) | -40°C ~ 105°C | - | - |
|
|
ISNB-0239-D202ISNB PULSE TRANSFORMER SMD 0.17A |
1,627 | 3.22 |
|
Datasheet |
IS | Tape & Reel (TR) | Active | SCR and Triac Trigger (Encapsulated) | 1.8mH | 350VµS | 2:1 | Surface Mount | 0.878" L x 0.894" W (22.30mm x 22.70mm) | 0.551" (14.00mm) | -25°C ~ 100°C | - | - |
|
|
HXU4009NLMDL SIN 2.5GPP 1:1 SMT TU |
2,450 | 6.97 |
|
- |
- | Tube | Active | - | - | - | - | - | - | - | - | - | - |
|
|
TG110-RP16NV6RLTRISO MOD 10/100 QUAD POE 0.35A |
2,369 | 0.00 |
|
- |
- | Tape & Reel (TR) | Not For New Designs | Power over Ethernet (PoE) | 350µH | - | 1CT:1CT | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.280" (7.11mm) | 0°C ~ 70°C | - | - |
|
|
TG1G-E201NV6LFTRISO MOD 1G DUAL X-TEMP 48P SMD T |
3,497 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10/100 Base-T | - | - | - | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.280" (7.11mm) | -40°C ~ 85°C | - | - |
|
|
HX6188NLMDL SIN 1GPP 1:1 4PUPOE TU |
1,379 | 7.02 |
|
Datasheet |
- | Tube | Active | LAN 1000 Base-T | 350µH | - | 1:1 | Surface Mount | 0.715" L x 0.511" W (18.16mm x 12.98mm) | 0.400" (10.16mm) | -40°C ~ 85°C | - | - |
|
|
HX6188NLTMDL SIN 1GPP 1:1 4PUPOE TR |
3,404 | 7.02 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 1000 Base-T | 350µH | - | 1:1 | Surface Mount | 0.715" L x 0.511" W (18.16mm x 12.98mm) | 0.400" (10.16mm) | -40°C ~ 85°C | - | - |
|
|
GH5610RSY-3 LFMDL 1G DIP QUAD PORTS POE+ 30W |
3,883 | 7.06 |
|
Datasheet |
- | Tube | Active | LAN 1000 Base-T | 350µH | - | 1:1CT Transmitter, 1:1CT Receiver | Through Hole | 1.142" L x 1.043" W (29.00mm x 26.50mm) | 0.512" (13.00mm) | 0°C ~ 70°C | - | - |
|
PE-68026NL10BT FILTER MODULE WITH CMC |
4,202 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | Isolation and Data Interface (Encapsulated) | - | - | 1:1 | Surface Mount | 0.920" L x 0.385" W (23.37mm x 9.78mm) | 0.230" (5.84mm) | 0°C ~ 70°C | - | - |
|
|
TG110-RPE17NV6RLISO MOD 10/100 QUAD POE 0.35A 48 |
4,364 | 0.00 |
|
Datasheet |
- | Tube | Not For New Designs | LAN 10/100 Base-TX | - | - | - | Surface Mount | 1.100" L x 0.480" W (27.94mm x 12.19mm) | 0.280" (7.11mm) | -40°C ~ 85°C | - | - |
|
|
T2SD02LN6MDL 10G DUAL PORT N/A |
4,214 | 7.10 |
|
Datasheet |
- | Tape & Reel (TR) | Active | LAN 10 Base-T | 100µH | - | 1:1CT Transmitter, 1:1CT Receiver | Surface Mount | 1.291" L x 0.543" W (32.80mm x 13.80mm) | 0.287" (7.30mm) | -40°C ~ 90°C | - | - |
|
|
TX1281PULSE XFMR 1CT:1 2MH |
2,134 | 7.38 |
|
Datasheet |
- | Tray | Active | - | 2mH | - | 1CT:1 | Surface Mount | 0.220" L x 0.230" W (5.59mm x 5.84mm) | 0.200" (5.08mm) | -40°C ~ 85°C | - | - |
|
|
TG10G-HPE10NZ5LFISO MOD 10G POE 1A X-TEMP 24P SM |
2,979 | 0.00 |
|
Datasheet |
- | Tube | Active | LAN 10G Base-T | - | - | - | Surface Mount | 0.722" L x 0.487" W (18.34mm x 12.37mm) | 0.255" (6.48mm) | -40°C ~ 85°C | - | - |
