Common Mode Chokes
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Package/Case | Filter Type | Number of Lines | Impedance @ Frequency | Current Rating (Max) | DC Resistance (DCR) (Max) | Voltage Rating - DC | Voltage Rating - AC | Operating Temperature | Ratings | Approval Agency | Features | Mounting Type | Size / Dimension | Height (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LCF121002C900TGCMC 150MA 2LN 90 OHM SMD |
6,643 | 0.65 |
|
Datasheet |
0504 (1210 Metric), 4 Lead | Signal Line | 2 | 90 Ohms @ 100 MHz | - | 150mA | 4Ohm | - | - | -40°C ~ 85°C | - | - | - | - | - |
|
|
LCF121002D900TGCMC 160MA 2LN 90 OHM SMD |
7,495 | 0.70 |
|
Datasheet |
0504 (1210 Metric), 4 Lead | Signal Line | 2 | 90 Ohms @ 100 MHz | - | 160mA | 4Ohm | - | - | -40°C ~ 85°C | - | - | - | - | - |
|
|
ACM 3225F2DV-101T01-D100 UH @ 100 KHZ 2 LINE COMMON M |
5,240 | 0.00 |
|
Datasheet |
Horizontal, 4 PC Pad | Signal Line | 2 | 5.1 kOhms @ 10 MHz | 100 µH @ 100 kHz | 150mA | 1.5Ohm | 80V | - | -55°C ~ 150°C | AEC-Q200 | - | - | - | - |
|
|
ACM 3225F2DV-110T03-D11 UH @ 100 KHZ 2 LINE COMMON MO |
3,670 | 0.00 |
|
Datasheet |
1210 (3225 Metric) | Signal Line | 2 | 550 Ohms @ 10 MHz | 11 µH @ 100 kHz | 300mA | 400mOhm | 80V | - | -55°C ~ 150°C | AEC-Q200 | - | - | - | - |
|
|
ACM 3225F2DV-220T02-D22 UH @ 100 KHZ 2 LINE COMMON MO |
3,526 | 0.00 |
|
Datasheet |
1210 (3225 Metric) | Signal Line | 2 | 1.1 kOhms @ 10 MHz | 22 µH @ 100 kHz | 250mA | 500mOhm | 80V | - | -55°C ~ 150°C | AEC-Q200 | - | - | - | - |
|
|
ACM 3225F2DV-510T02-D51 UH @ 100 KHZ 2 LINE COMMON MO |
2,796 | 0.00 |
|
Datasheet |
1210 (3225 Metric) | Signal Line | 2 | 2.6 kOhms @ 10 MHz | 51 µH @ 100 kHz | 200mA | 700mOhm | 80V | - | -55°C ~ 150°C | AEC-Q200 | - | - | - | - |
|
MCZ1210CH900L2CMC 100MA 2LN 90 OHM SMD |
19,088 | 0.63 |
|
Datasheet |
0504 (1210 Metric), 4 Lead | Signal Line | 2 | 90 Ohms @ 100 MHz | - | 100mA | 3Ohm | 5V | - | -40°C ~ 85°C | - | - | - | - | - |
|
EMI4184MUTAGCMC 100MA 8LN SMD ESD |
4,857 | 0.52 |
|
Datasheet |
20-UFDFN | Signal Line | 8 | - | - | 100mA | 8Ohm (Typ) | - | - | -40°C ~ 85°C | - | - | TVS Diode ESD Protection | - | - |
|
DLW32SH110XK2LCMC 11UH 300MA 2LN SMD AEC-Q200 |
7,939 | 0.59 |
|
Datasheet |
Horizontal, 4 PC Pad | - | 2 | - | 11 µH @ 100 kHz | 300mA | 400mOhm | 80V | - | -40°C ~ 125°C | AEC-Q200 | - | - | - | - |
|
TCM0605G-650-2P-T201CMC 100MA 2LN 65 OHM SMD |
4,488 | 0.62 |
|
Datasheet |
0202 (0505 Metric), 4 PC Pad | Signal Line | 2 | 65 Ohms @ 100 MHz | - | 100mA | 2.7Ohm | 10V | - | -25°C ~ 85°C | - | - | - | - | - |
|
ACM2012E-670-2P-T01CMC 500MA 2LN 67 OHM SMD |
1,476 | 0.61 |
|
Datasheet |
Horizontal, 4 PC Pad | Signal Line | 2 | 67 Ohms @ 100 MHz | - | 500mA | 350mOhm | 50V | - | -40°C ~ 85°C | - | - | - | - | - |
-8-Lead-DLP2A-Series.jpg)
|
DLP2ADN201HL4LCMC 90MA 4LN 200 OHM SMD |
20,174 | 0.74 |
|
Datasheet |
0804 (2010 Metric), 8 Lead | Signal Line | 4 | 200 Ohms @ 100 MHz | - | 90mA | 4Ohm | 5V | - | -40°C ~ 85°C | - | - | - | - | - |
|
|
DLP2ADN121HL4LCMC 120MA 4LN 120 OHM SMD |
113,599 | 0.74 |
|
Datasheet |
0804 (2010 Metric), 8 Lead | Signal Line | 4 | 120 Ohms @ 100 MHz | - | 120mA | 2.5Ohm | 5V | - | -40°C ~ 85°C | - | - | - | - | - |
|
TCM0806G-151-2PCMC 50MA 2LN 150 OHM SMD |
6,728 | 0.68 |
|
Datasheet |
0302 (0806 Metric), 4 Lead | Signal Line | 2 | 150 Ohms @ 100 MHz | - | 50mA | 3.5Ohm | 10V | - | -25°C ~ 85°C | - | - | - | - | - |
|
|
FL2D-30-103COMMON MODE FILTER 10MH 3A TH |
2,546 | 0.00 |
|
Datasheet |
Horizontal, 4 PC Pin | - | 2 | - | 10 mH @ 1 kHz | 3A | 50mOhm (Typ) | - | - | -40°C ~ 105°C | - | - | - | - | - |
|
PE-0805CCMC361STSCMC 280MA 2LN 360 OHM SMD |
11,013 | 0.68 |
|
Datasheet |
Horizontal, 4 PC Pad | Signal Line | 2 | 360 Ohms @ 100 MHz | - | 280mA | 450mOhm | 50V | - | - | - | - | - | - | - |
|
|
TCM0806S-350-2PCMC 100MA 2LN 35 OHM SMD |
10,268 | 0.81 |
|
Datasheet |
0302 (0806 Metric), 4 Lead | Signal Line | 2 | 35 Ohms @ 100 MHz | - | 100mA | 1.5Ohm | 10V | - | -25°C ~ 85°C | - | - | - | - | - |
|
|
ACM 3225F2UV-201T007-S200 UH @ 100 KHZ 2 LINE COMMON M |
7,390 | 0.00 |
|
Datasheet |
Horizontal, 4 PC Pad | Signal Line | 2 | - | 200 µH @ 100 kHz | 70mA | 5.5Ohm | 80V | - | -40°C ~ 125°C | AEC-Q200 | - | - | - | - |
|
|
WCM 7060FASF-132-LM2 LINE COMMON MODE CHOKE SURFACE |
3,900 | 0.00 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | 1.3 kOhms @ 100 MHz | - | 3A | 20mOhm | 80V | - | -40°C ~ 125°C | - | - | - | - | - |
|
|
WCM 7060FASF-102-LM2 LINE COMMON MODE CHOKE SURFACE |
1,383 | 0.00 |
|
Datasheet |
Horizontal, 4 PC Pad | Power Line | 2 | 1.02 kOhms @ 100 MHz | - | 3A | 17mOhm | 80V | - | -40°C ~ 125°C | - | - | - | - | - |
