Pulse Transformers
| Photo | Mfr. Part # | Availability | Price | Quantity | Datasheet | Series | Packaging | Product Status | Transformer Type | Inductance | ET (Volt-Time) | Turns Ratio - Primary:Secondary | Mounting Type | Size / Dimension | Height - Seated (Max) | Operating Temperature | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
T1038PULSE XFMR 1CT:1CT 1CT:1.36CT |
2,096 | 0.00 |
|
Datasheet |
- | Tube | Active | - | 1.2mH, 1.2mH | - | 1CT:1CT Transmitter, 1CT:1.36CT Receiver | Surface Mount | 0.950" L x 0.589" W (24.13mm x 14.96mm) | 0.395" (10.03mm) | 0°C ~ 70°C | - | - |
|
|
T1076PULSE XFMR 1CT:1.15CT 1CT:2CT |
4,802 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | - | - | - | 1CT:1.15CT Transmitter, 1CT:2CT Receiver | Surface Mount | 0.505" L x 0.280" W (12.83mm x 7.11mm) | 0.245" (6.22mm) | -40°C ~ 85°C | - | - |
|
|
T1105PULSE XFMR 1:2CT TX/RX 1.2MH |
4,726 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | T1/E1 (Quad) | 1.2mH, 1.2mH | - | 1:2CT Transmitter, 1:2CT Receiver | Surface Mount | 1.125" L x 0.485" W (28.58mm x 12.32mm) | 0.230" (5.84mm) | -40°C ~ 85°C | - | - |
|
|
T1231PULSE XFMR 1:2.4 TX 1:1 RX |
4,222 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | T1/E1 (Quad) | 1mH, 1mH | - | 1:2.4 Transmitter, 1:1 Receiver | Surface Mount | 1.125" L x 0.485" W (28.58mm x 12.32mm) | 0.230" (5.84mm) | -40°C ~ 85°C | - | - |
|
|
T9030PULSE XFMR 1CT:2 TX 1CT:1 RX |
1,934 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | T1/E1 (Quad) | 1.2mH | - | 1CT:2 Transmitter, 1CT:1 Receiver | Surface Mount | 1.255" L x 0.712" W (31.88mm x 18.08mm) | 0.305" (7.75mm) | -40°C ~ 85°C | - | - |
|
|
TX9025PULSE XFMR 1:2 1:2 1.2MH |
4,005 | 0.00 |
|
- |
- | Tube | Obsolete | T1/E1 (Quad) | 1.2mH | - | 1:2, 1:2 | Surface Mount | 1.125" L x 0.485" W (28.58mm x 12.32mm) | 0.285" (7.24mm) | -40°C ~ 85°C | - | - |
|
|
TX1341PULSE XFMR 1:2 1.2MH |
1,222 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | T1/E1 (Quad) | 1.2mH | - | 1:2 | Surface Mount | 1.000" L x 0.310" W (25.40mm x 7.87mm) | 0.295" (7.49mm) | -40°C ~ 85°C | - | - |
|
|
T7015PULSE XFMR 1CT:2CT TX/RX 20MH |
1,098 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | - | 20mH | - | 1CT:2CT Transmitter, 1CT:2CT Receiver | Surface Mount | 0.675" L x 0.456" W (17.15mm x 11.58mm) | 0.340" (8.64mm) | 0°C ~ 70°C | - | - |
|
|
TX1089PULSE XFMR 1CT:1:26CT TX/RX |
4,822 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | - | - | - | 1CT:1:26CT Transmitter, 1CT:1:26CT Receiver | Surface Mount | 0.505" L x 0.280" W (12.83mm x 7.11mm) | 0.245" (6.22mm) | -40°C ~ 85°C | - | - |
|
|
T3011PULSE XFMR 1:1 100UH |
3,816 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | - | 100µH | - | 1:1 | Surface Mount | 0.300" L x 0.276" W (7.62mm x 7.00mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
|
TX1315PULSE XFMR 1CT:1CT 1.2MH |
3,617 | 0.00 |
|
Datasheet |
- | Tube | Obsolete | - | 1.2mH | - | 1CT:1CT | Surface Mount | 0.300" L x 0.276" W (7.62mm x 7.00mm) | 0.250" (6.35mm) | -40°C ~ 85°C | - | - |
|
PT61022ELPULSE XFMR 1CT:1 350UH |
1,636 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Obsolete | LAN 10/100/1000 Base-T | 350µH | - | 1CT:1 | Surface Mount | 0.539" L x 0.600" W (13.70mm x 15.24mm) | 0.205" (5.20mm) | 0°C ~ 70°C | - | - |
|
SM51108ELPULSE XFMR 1CT:1CT 350UH |
4,329 | 0.00 |
|
Datasheet |
- | Tape & Reel (TR) | Obsolete | LAN 10/100 Base-T | 350µH | - | 1CT:1CT | Surface Mount | 0.472" L x 0.276" W (12.00mm x 7.00mm) | 0.215" (5.45mm) | -40°C ~ 85°C | - | - |
|
|
C10120PULSE XFMR 2:1 1.5MH |
3,739 | 0.00 |
|
Datasheet |
CEP | Tape & Reel (TR) | Active | ADSL, HDSL, SHDSL, VDSL | 1.5mH | - | 2:1 | Surface Mount | 0.531" L x 0.697" W (13.50mm x 17.70mm) | 0.484" (12.30mm) | - | - | - |
|
|
C10136PULSE XFMR 2:1 100UH |
4,710 | 0.00 |
|
Datasheet |
CEP | Tape & Reel (TR) | Active | ADSL, HDSL, SHDSL, VDSL | 100µH | - | 2:1 | Surface Mount | 0.531" L x 0.697" W (13.50mm x 17.70mm) | 0.484" (12.30mm) | - | - | - |
|
|
CLP42B-201200UH LAN PULSE TRAN 1CT:1CT SMD |
3,331 | 0.00 |
|
Datasheet |
CLP42B | Tape & Reel (TR) | Active | LAN | 200µH | 1.5VµS | 1CT:1CT | Surface Mount | 0.370" L x 0.181" W (9.40mm x 4.60mm) | 0.098" (2.50mm) | - | - | - |
|
|
J14202PULSE XFMR 2.5:1 420UH |
1,525 | 0.00 |
|
Datasheet |
CEP | Tape & Reel (TR) | Active | VDSL | 420µH | - | 2.5:1 | Surface Mount | 0.315" L x 0.319" W (8.00mm x 8.10mm) | 0.374" (9.50mm) | - | - | - |
|
|
J14207PULSE XFMR 2.5:1 420UH |
4,634 | 0.00 |
|
Datasheet |
CEP | Tape & Reel (TR) | Active | VDSL | 420µH | - | 2.5:1 | Surface Mount | 0.315" L x 0.319" W (8.00mm x 8.10mm) | 0.374" (9.50mm) | - | - | - |
|
|
J14208PULSE XFMR 2.5:1 100UH |
1,597 | 0.00 |
|
Datasheet |
CEP | Tape & Reel (TR) | Active | VDSL | 100µH | - | 2.5:1 | Surface Mount | 0.315" L x 0.319" W (8.00mm x 8.10mm) | 0.374" (9.50mm) | - | - | - |
|
|
J14214PULSE XFMR 2:1 420UH |
1,081 | 0.00 |
|
Datasheet |
CEP | Tape & Reel (TR) | Active | VDSL | 420µH | - | 2:1 | Surface Mount | 0.315" L x 0.319" W (8.00mm x 8.10mm) | 0.374" (9.50mm) | - | - | - |
